(pytorch advanced path 2) word embedding and position embedding

word embedding

embedding The function is to discretize the high dimension token Mapping to low dimensional dense token
Suppose a task background ： English translation German , First we need to construct an English sentence Source sequence source sentence And a target sequence target sentence German , Source sequence src_seq and Target sequence tgt_seq
How to build a sequence ？ Come into contact with NLP It should be no stranger , The characters of the sequence are represented by a word list dict In the form of an index of

Specified sequence length , Assuming that src and tgt len

# %%
import numpy
import torch as T
import torch.nn as nn
import torch.nn.functional as F
# %%
#  Suppose there are two sentences
batch_size = 2
#  Each sentence is... Long 2~5
src_len = T.randint(2, 5, (batch_size, ))
tgt_len = T.randint(2, 5, (batch_size, ))
#  Convenient research , We write dead
src_len = T.Tensor([2, 4]).to(T.int32)
tgt_len = T.Tensor([4, 3]).to(T.int32)
print(src_len)
print(tgt_len)

Output results tensor([2, 4]),tensor([4, 2]), explain src The length of the sentence is 2 and 4,tgt The length of the sentence is 4 and 2, There are two sentences

Then we build seq, hypothesis src and tgt dict The maximum sequence number is 8, The maximum number of words is 8, Random generation seq Put in list, In order to keep the sentence length consistent , I still need padding operation , Use functional Inside pad function , After that, the sequence uses unsqueeze、cat convert to [batch_size, max_len] Formal tensor As batch Input

# %%
#  Word list size
max_source_word_num = 8
max_target_word_num = 8
#  Maximum sequence length
max_source_seq_len = 5
max_target_seq_len = 5
#  Generate seq
src_seq = [T.randint(1, max_source_word_num, (L,)) for L in src_len]
# padding
src_seq = list(map(lambda x: F.pad(x, (0, max_source_seq_len - len(x))), src_seq))
#  L one dimension is convenient for us to splice
src_seq = list(map(lambda x: T.unsqueeze(x, 0), src_seq))
#  Splicing
src_seq = T.cat(src_seq, 0)
print(src_seq)

tgt_seq = [F.pad(T.randint(1, max_target_word_num, (L,)), (0, max_target_seq_len-L)) for L in tgt_len]
tgt_seq = list(map(lambda x: T.unsqueeze(x, 0), tgt_seq))
tgt_seq = T.cat(tgt_seq, 0)
print(tgt_seq)

Output results ：

Input complete , The middle part embedding, Use pytorch Of API,nn.Embedding
The first parameter num_embeddings, Number of words , We usually take the maximum vocabulary size + 1,padding Of 0 You count
The second parameter embedding_dim, Word vector dimension , It's usually 512, It is convenient for us to take 8

# %%
model_dim = 8
#  structure embedding table
src_embedding_table = nn.Embedding(max_source_word_num + 1, model_dim)
tgt_embedding_table = nn.Embedding(max_target_word_num + 1, model_dim)
print(src_embedding_table.weight.size())

#  Test it forward
src_embedding = src_embedding_table(src_seq)
print(src_embedding.size())

position embedding

Attention is all you need There is PE（position embedding） The expression of , The general idea is to convert the position information of the word in the sentence into a vector , And again WE（word embedding） Add up

First PE It's a two-dimensional matrix ：[max_len, dim], The maximum length can be the same as max_source_seq_len Agreement , It is stipulated here max_position_len=5
PE A matrix can be thought of as a multiplication of two matrices （ Not matrix multiplication but element by element multiplication ）, A matrix is pos（/ On the left ）, Another matrix is i（/ On the right ）, Odd sequence and even sequence are multiplied respectively sin and cos

# %%
max_position_len = 5
pos_matrix = T.arange(max_position_len).reshape((-1, 1))
print(pos_matrix)

#  Because there are odd and even numbers , So the interval is 2
i_matrix = T.pow(10000, T.arange(0, model_dim, 2).reshape([1, -1]) / model_dim)
print(i_matrix)
#  structure embedding matrix
pe_embedding_table = T.zeros([max_position_len, model_dim])
#  Even columns , The line doesn't change ,0：：2 Even columns , It means subscript from 0 Start , Until the last , Take the step of 2 All elements of
pe_embedding_table[:, 0::2] = T.sin(pos_matrix / i_matrix)
#  Odd columns
pe_embedding_table[:, 1::2] = T.cos(pos_matrix / i_matrix)
print(pe_embedding_table)

structure nn.Module, Replace weight

# %%
#  rewrite nn Module weight Way to create pe embedding
pe_embedding = nn.Embedding(max_position_len, model_dim)
pe_embedding.weight = nn.Parameter(pe_embedding_table, requires_grad=False)
print(pe_embedding.weight.size())

Construct input , We need to pass in the location index , Nature is to use range Operation , At last, calculate PE

# %%
#  Construct location index
src_pos = T.cat([T.unsqueeze(T.arange(max_position_len), 0) for _ in src_len] , 0)
print(src_pos)

tgt_pos = T.cat([T.unsqueeze(T.arange(max_position_len), 0) for _ in tgt_len] , 0)
# forword Calculation src-pe
src_pe_embedding = pe_embedding(src_pos)
print(src_pe_embedding.size())

Complete code

# %%
from pyexpat import model
from turtle import pos
import numpy
import torch as T
import torch.nn as nn
import torch.nn.functional as F
# %%
#  Suppose there are two sentences
batch_size = 2
#  Each sentence is... Long 2~5
src_len = T.randint(2, 5, (batch_size, ))
tgt_len = T.randint(2, 5, (batch_size, ))
print(src_len)
print(tgt_len)
#  Convenient research , We write dead
src_len = T.Tensor([2, 4]).to(T.int32)
tgt_len = T.Tensor([4, 3]).to(T.int32)
print(src_len)
print(tgt_len)
# %%
#  Word list size
max_source_word_num = 8
max_target_word_num = 8
#  Maximum sequence length
max_source_seq_len = 5
max_target_seq_len = 5
#  Generate seq
src_seq = [T.randint(1, max_source_word_num, (L,)) for L in src_len]
# padding
src_seq = list(map(lambda x: F.pad(x, (0, max_source_seq_len - len(x))), src_seq))
#  L one dimension is convenient for us to splice
src_seq = list(map(lambda x: T.unsqueeze(x, 0), src_seq))
#  Splicing
src_seq = T.cat(src_seq, 0)
print(src_seq)

tgt_seq = [F.pad(T.randint(1, max_target_word_num, (L,)), (0, max_target_seq_len-L)) for L in tgt_len]
tgt_seq = list(map(lambda x: T.unsqueeze(x, 0), tgt_seq))
tgt_seq = T.cat(tgt_seq, 0)
print(tgt_seq)

# %%
model_dim = 8
src_embedding_table = nn.Embedding(max_source_word_num + 1, model_dim)
tgt_embedding_table = nn.Embedding(max_target_word_num + 1, model_dim)
print(src_embedding_table.weight.size())

#  Test it forward
src_embedding = src_embedding_table(src_seq)
print(src_embedding.size())
# %%

# %%
max_position_len = 5
pos_matrix = T.arange(max_position_len).reshape((-1, 1))
print(pos_matrix)

#  Because there are odd and even numbers , So the interval is 2
i_matrix = T.pow(10000, T.arange(0, model_dim, 2).reshape([1, -1]) / model_dim)
print(i_matrix)
#  structure embedding matrix
pe_embedding_table = T.zeros([max_position_len, model_dim])
#  Even columns , The line doesn't change ,0：：2 Even columns , It means subscript from 0 Start , Until the last , Take the step of 2 All elements of
pe_embedding_table[:, 0::2] = T.sin(pos_matrix / i_matrix)
#  Odd columns
pe_embedding_table[:, 1::2] = T.cos(pos_matrix / i_matrix)
print(pe_embedding_table)
# %%
#  rewrite nn Module weight Way to create pe embedding
pe_embedding = nn.Embedding(max_position_len, model_dim)
pe_embedding.weight = nn.Parameter(pe_embedding_table, requires_grad=False)
print(pe_embedding.weight.size())


# %%
#  Construct location index
src_pos = T.cat([T.unsqueeze(T.arange(max_position_len), 0) for _ in src_len] , 0)
print(src_pos)

tgt_pos = T.cat([T.unsqueeze(T.arange(max_position_len), 0) for _ in tgt_len] , 0)
# forword Calculation src-pe
src_pe_embedding = pe_embedding(src_pos)
print(src_pe_embedding.size())
