Database connection pool: implementation of connection pool function point

Connection pool function

It mainly contains the following functions ：

1. Connection pooling in singleton mode , Constructor needs to be privatized
2. You need a function to get the connection
3. Functions to load configuration files
4. Producer thread , Used to produce connections
5. A function used to reclaim redundant idle connections , Independent threads

Data members have ：

6. Information required by the database
7. The initial and maximum connections of the connection pool
8. The maximum waiting time of the connection pool
9. The timeout for the connection pool to obtain connections
10. Storage MySQL Connected queue
11. Maintain the mutex of the connection queue
12. Atomic integer operations , Record the number of connections
13. Condition variables, , For communication between producer and consumer threads .

Icon ：

Therefore, header information can be written ：

Connection pool header file

#pragma once
//  Implement the connection pool function module
#include<iostream>
#include<string>
#include<queue>
#include<mutex>
#include<atomic>
#include<thread>
#include<memory>
#include<functional>
#include<condition_variable>
#include "Connection.h"

using namespace std;

class ConnectionPool
{

public:
	//  Get connection pool object instance   Static
	static ConnectionPool* getConnectionPool();

	//  Provide an interface to the outside , Provide an idle connection
	shared_ptr<Connection> getConnection();

private:
	ConnectionPool(); //  The singleton pattern   Constructor privatization

	bool loadConfigFile(); //  Load profile

	//  Producer thread function ,  Responsible for the production of new connections
	void produceConnectionTask();

	//  Recycling thread functions , Responsible for recycling redundant idle connections
	void scannerConnectionTask();

	string _ip;				// MySQL Of IP Address
	unsigned short _port;	// MySQL Port number
	string _username;		// MySQL Login user name of
	string _password;		// MySQL Login password for
	string _dbname;			//  Database name

	int _initSize;			//  The initial number of connections to the connection pool
	int _maxSize;			//  The maximum number of connections in the connection pool
	int _maxIdleTime;		//  The maximum waiting time of the connection pool
	int _connectionTimeOut;	//  The timeout for the connection pool to obtain connections

	queue<Connection*> _connectionQue; //  Storage MySQL Connected queue

	mutex _queueMutex;			//  Maintain thread safe mutexes for connection queues
	atomic_int _connectionCnt;	//  Record the... Created by the connection connection Total connections for , No more than _maxSize
	condition_variable cv;		//  Connect the communication between the production thread and the consumption thread
};

Function realization

Connection pooling in singleton mode

The lazy singleton mode is used here , The compiler performs the locking operation itself

//  Thread safe lazy singleton mode function interface
ConnectionPool* ConnectionPool::getConnectionPool()
{

	//  Static local variables , Compiler automatic lock and unlock
	static ConnectionPool pool;
	return& pool;
}

MySQL The configuration file

stay Windows The suffix of this file is MySQL.ini

#  Configuration file of database connection pool
ip=127.0.0.1
port=3306
username=root
password=123456
dbname=chat
initSize=10
maxSize=1024
#  The maximum idle time is seconds by default
maxIdleTime=60
#  Connection timeout , In milliseconds
connectionTimeOut=100

Read configuration file

//  Load configuration items from the configuration file
bool ConnectionPool::loadConfigFile()
{

	FILE* pf = fopen("mysql.ini", "r");
	if (pf == nullptr)
	{

		LOG("mysql.ini file is not exist!");
		return false;
	}

	while (!feof(pf))
	{

		char line[1024] = {
     0 };
		fgets(line, 1024, pf);
		string str = line;
		int idx = str.find('=', 0);
		if (-1 == idx) //  Invalid configuration
		{

			continue;
		}

		int endidx = str.find('\n', idx);
		string key = str.substr(0, idx);
		string value = str.substr(idx + 1, endidx - idx - 1);

		if (key == "ip")
		{

			_ip = value;
		}
		else if (key == "port")
		{

			_port = atoi(value.c_str());
		}
		else if (key == "username")
		{

			_username = value;
		}
		else if (key == "password")
		{

			_password = value;
		}
		else if (key == "dbname")
		{

			_dbname = value;
		}
		else if (key == "initSize")
		{

			_initSize = atoi(value.c_str());
		}
		else if (key == "maxSize")
		{

			_maxSize = atoi(value.c_str());
		}
		else if (key == "maxIdleTime")
		{

			_maxIdleTime = atoi(value.c_str());
		}
		else if (key == "connectionTimeOut")
		{

			_connectionTimeOut = atoi(value.c_str());
		}
	}
	return true;
}

Producer thread implementation

//  producer ： Running on a separate thread , Responsible for production connection
void ConnectionPool::produceConnectionTask()
{

	//  loop （ Keep listening ）
	for (; ;)
	{

		unique_lock<mutex> lock(_queueMutex);
		while (!_connectionQue.empty())
		{

			cv.wait(lock); //  The queue is not empty , The production thread enters the waiting queue for the condition variable
		}

		//  The number of connections has not reached the maximum , Continue creating new connections
		if (_connectionCnt < _maxSize)
		{

			Connection* p = new Connection();
			p->connect(_ip, _port, _username, _password, _dbname);

			p->refreshAliveTime();	//  Refresh the start time of idle
			_connectionQue.push(p);
			_connectionCnt++;
		}

		//  Wake up all threads in the waiting queue
		cv.notify_all();	//  Notify consumer thread ,  You can consume and connect
	}
}

Consumer function realization

//  Provide an interface to the outside , Provide an idle connection
shared_ptr<Connection> ConnectionPool::getConnection()
{

	unique_lock<mutex> lock(_queueMutex);
	while (_connectionQue.empty())
	{

		//  Not directly sleep
		//  When I wake up after a timeout, I find that it is still empty , Just go back to nullptr
		if (cv_status::timeout == cv.wait_for(lock, std::chrono::milliseconds(_connectionTimeOut)))
		{

			if (_connectionQue.empty())
			{

				LOG(" Getting idle connection timed out ... Failed to get connection ！");
				return nullptr;
			}
		}
	}

	/*  because shared_ptr At the time of deconstruction , Will be able to Connection Resource Direct delete fall ,  Equivalent to calling Connection Destructor of ,Connection I was close It fell off ,  So you need to customize how smart pointers release resources , Instead, return the resource to the queue  */
	shared_ptr<Connection> sp(_connectionQue.front(),
		[&](Connection* pcon) {

			//  This is called in the server application thread. , Thread safety needs to be considered
			unique_lock<mutex> lock(_queueMutex);

			pcon->refreshAliveTime();	//  Refresh the start time of idle
			_connectionQue.push(pcon);
		});
	_connectionQue.pop();

	//  Consume the last one in the queue Connection, The producer thread is notified of the production connection
	cv.notify_all();
	return sp;
}

Redundant connection recycling , Independent threads

Need here MySQL Implement two functions in the connected class ：

clock_t _aliveTime; //  Record the survival time after entering the idle state

//  Refresh the starting idle time of the connection
void Connection::refreshAliveTime()
{

	_aliveTime = clock();
}

//  Return to the time of survival
clock_t Connection::getAliveTime() const
{

	return clock() - _aliveTime;
}

Then let's look at the recycling function

//  Scan over maxIdleTime Of free connections , Recycle excess connections
void ConnectionPool::scannerConnectionTask()
{

	for (; ;)
	{

		//  adopt sleep Simulate the timing effect
		this_thread::sleep_for(std::chrono::seconds(_maxIdleTime));

		//  Scan the entire queue , Release more than connections
		unique_lock<mutex> lock(_queueMutex);
		while (_connectionCnt > _initSize)
		{

			Connection* p = _connectionQue.front();
			if (p->getAliveTime() >= (_maxIdleTime * 1000))
			{

				_connectionQue.pop();
				_connectionCnt--;
				delete p;	//  call  ~Connection();
			}
			else
			{

				break; //  The connection of the team head does not exceed _maxIdleTime, There must be none in the back
			}
		}
	}
}
