LVS-DR Mode multi segment case

1. Experimental framework

Principle supplement ：
The router eth0 To configure two ip, Because in different network segments ,rs and lvs Of VIP and RIP Not in the same network segment ,lo：VIP172.168.100/32 Must be 32 Bit ,24 No, I can't , Because it is configured on the loopback network card , The loopback network card has no route , As long as they are in the same network segment , To be able to connect , If it is 24 A word of ,172.16.0.200 and 172.168.100 In the same segment , Will be in the local circle , Cannot forward to 172.16.0.200, Therefore, you must set 32 position , There are no other hosts in the same network segment , Can be forwarded to 172.16.0.200 了 , If bound to eth0 There is no such problem .

2. Experimental environment

 Environmental Science ： Five hosts
 a ： client  eth0: Host only  192.168.10.6/24 GW:192.168.10.200

 a ：ROUTER
eth0 :NAT 10.0.0.200/24  NAT 172.16.0.200/24
eth1:  Host only  192.168.10.200/24
 Enable  IP_FORWARD

 a ：LVS
eth0:NAT:DIP:10.0.0.8/24 GW:10.0.0.200
lo:VIP 172.16.0.100/32

 Two sets of RS：
RS1：eth0:NAT:10.0.0.7/24 GW：10.0.0.200
lo:VIP 172.16.0.100/32
RS2：eth0:NAT:10.0.0.17/24 GW：10.0.0.200
lo:VIP 172.16.0.100/32

3. Back end RS1 Of IPVS To configure

1. Modify hostname
[[email protected]:~]#
hostnamectl set-hostname rs1.magedu.org && exit

2. install httpd service
[[email protected]:~]#
yum -y install httpd;echo rs1 `hostname -I` > /var/www/html/index.html;systemctl enable --now httpd

3. Modify the gateway to 10.0.0.200,dns It will not be on , You can delete
[[email protected]:~]#
vim /etc/sysconfig/network-scripts/ifcfg-eth0
DEVICE=eth0
NAME=eth0
BOOTPROTO=static
IPADDR=10.0.0.7
PREFIX=24
GATEWAY=10.0.0.200
DNS1=10.0.0.2
DNS2=180.76.76.76
ONBOOT=yes
[[email protected]:~]#
systemctl restart network

4. binding VIP To lo Looback adaptor , Turn it off at the same time lo Looback adaptor arp
[[email protected]:~]#
echo 1 > /proc/sys/net/ipv4/conf/all/arp_ignore
[[email protected]:~]#
echo 1 > /proc/sys/net/ipv4/conf/lo/arp_ignore
# Turn off the main switch and the specific network card switch .

[[email protected]:~]#
echo 2 > /proc/sys/net/ipv4/conf/all/arp_announce
[[email protected]:~]#
echo 2 > /proc/sys/net/ipv4/conf/lo/arp_announce

5.  To configure VIP Address
[[email protected]:~]#
cp /etc/sysconfig/network-scripts/ifcfg-lo /etc/sysconfig/network-scripts/ifcfg-lo:1
[[email protected]:~]#
vim /etc/sysconfig/network-scripts/ifcfg-lo:1
DEVICE=lo:1
IPADDR=172.16.0.100
NETMASK=255.255.255.255
ONBOOT=yes
NAME=loopback1
[[email protected]:~]#
systemctl restart network
# Temporary configuration method , No need to restart
ifconfig lo:1 10.0.0.100/32

4. Back end RS2 Of IPVS To configure

1. Modify hostname
[[email protected]:~]#
hostnamectl set-hostname rs2.magedu.org && exit

2. install httpd service
[[email protected]:~]#
yum -y install httpd;echo rs1 `hostname -I` > /var/www/html/index.html;systemctl enable --now httpd

3. Modify the gateway to 10.0.0.200,dns It will not be on , You can delete
[[email protected]:~]#
vim /etc/sysconfig/network-scripts/ifcfg-eth0
DEVICE=eth0
NAME=eth0
BOOTPROTO=static
IPADDR=10.0.0.17
PREFIX=24
GATEWAY=10.0.0.200
DNS1=10.0.0.2
DNS2=180.76.76.76
ONBOOT=yes
[[email protected]:~]#
systemctl restart network

4. binding VIP To lo Looback adaptor , Turn it off at the same time lo Looback adaptor arp
[[email protected]:~]#
echo 1 > /proc/sys/net/ipv4/conf/all/arp_ignore
[[email protected]:~]#
echo 1 > /proc/sys/net/ipv4/conf/lo/arp_ignore
# Turn off the main switch and the specific network card switch .

[[email protected]:~]#
echo 2 > /proc/sys/net/ipv4/conf/all/arp_announce
[[email protected]:~]#
echo 2 > /proc/sys/net/ipv4/conf/lo/arp_announce

5.  To configure VIP Address
[[email protected]:~]#
vim /etc/sysconfig/network-scripts/ifcfg-lo:1
DEVICE=lo:1
IPADDR=172.16.0.100
NETMASK=255.255.255.255
ONBOOT=yes
NAME=loopback1
[[email protected]:~]#
systemctl restart network
# Temporary configuration method , No need to restart
ifconfig lo:1 10.0.0.100/32

5.client Client network configuration

1. Modify NIC , The gateway must be configured , Because I want to be with rs Establish a connection directly .
[[email protected] ~]#vim /etc/netplan/01-netcfg.yaml
network:
  version: 2
  renderer: networkd
  ethernets:
    eth0:
      addresses: [192.168.10.6/24]
      gateway4: 192.168.10.200
      nameservers:
        search: [magedu.com, magedu.org]
        addresses: [180.76.76.76, 8.8.8.8, 1.1.1.1]
[[email protected] ~]#netplan apply
[[email protected] ~]#route -n
Kernel IP routing table
Destination     Gateway         Genmask         Flags Metric Ref    Use Iface
0.0.0.0         192.168.10.200  0.0.0.0         UG    0      0        0 eth0
192.168.10.0    0.0.0.0         255.255.255.0   U     0      0        0 eth0

6. Routing host configuration

1.vmware Add host only network card , See the figure below for details.

2. modify eth0 network card
[[email protected]:~]#
hostnamectl set-hostname route.magedu.org;exit
[[email protected]:~]# Gateway and dns Not available for parsing , You can delete .
vim /etc/sysconfig/network-scripts/ifcfg-eth0
DEVICE=eth0
NAME=eth0
BOOTPROTO=static
IPADDR1=10.0.0.200
PREFIX=24
IPADDR2=172.16.0.200
PREFIX=24
GATEWAY=10.0.0.2
DNS1=10.0.0.2
DNS2=180.76.76.76
ONBOOT=yes


3. To configure eth1 network card
[[email protected]:~]#
cp /etc/sysconfig/network-scripts/ifcfg-eth0 /etc/sysconfig/network-scripts/ifcfg-eth1
[[email protected]:~]#
vim /etc/sysconfig/network-scripts/ifcfg-eth1
DEVICE=eth1
NAME=eth1
BOOTPROTO=static
IPADDR=192.168.10.200
PREFIX=24
GATEWAY=10.0.0.2
DNS1=10.0.0.2
DNS2=180.76.76.76
ONBOOT=yes
[[email protected]:~]#
nmcli con reload
[[email protected]:~]#
nmcli con
NAME                UUID                                  TYPE      DEVICE
eth0                5fb06bd0-0bb0-7ffb-45f1-d6edd65f3e03  ethernet  eth0
eth1                9c92fad9-6ecb-3e6c-eb4d-8a47c6f50c04  ethernet  eth1
Wired connection 1  36a1faac-f944-3a4a-98d1-21929b079ddf  ethernet  --
4. Restart NIC
[[email protected]:~]#
nmcli con up eth1#
# It can also be deleted Wired connection 1
[[email protected]:~]#
nmcli con delete Wired\ connection\ 1  # You must add \

[[email protected]:~]#
nmcli con up eth0

5. Turn on forwarding
[[email protected]:~]#
vim /etc/sysctl.conf
net.ipv4.ip_forward=1
[[email protected]:~]#
sysctl -p

7.LVS Network configuration

1. Modify hostname
[[email protected]:~]#
hostnamectl set-hostname lvs.magedu.org && exit

2. Install related packages
[[email protected]:~]#
yum -y install ipvsadm


3. configure network , Gateway and dns You can delete , Because there is no need to access the Internet .
[[email protected]:~]#
vim /etc/sysconfig/network-scripts/ifcfg-eth0
DEVICE=eth0
NAME=eth0
BOOTPROTO=static
IPADDR=10.0.0.8
PREFIX=24
GATEWAY=10.0.0.200
DNS1=10.0.0.2
DNS2=180.76.76.76
ONBOOT=yes
[[email protected]:~]#
nmcli con reload
[[email protected]:~]#
nmcli con up eth0

5. Configure loopback network card ip, Temporary method .
[[email protected]:~]#
ifconfig lo:1 10.0.0.100/32
# Add in lo The last address on the network card （ Temporarily add ）
[[email protected]:~]#
ip a a 172.16.0.100/32 dev lo label lo:1  #lable  Is to add labels

8.LVS Host configuration lvs The rules

1. Add rules , Manage cluster services
[[email protected]:~]#
ipvsadm -A -t 172.16.0.100:80 -s wrr

2. Add rules , Manage... In the cluster rs
[[email protected]:~]#
ipvsadm -a -t 172.16.0.100:80 -r 10.0.0.7:80 -g -w 1
[[email protected]:~]#
ipvsadm -a -t 172.16.0.100:80 -r 10.0.0.17:80 -g -w 1
[[email protected]:~]#
ipvsadm -Ln
IP Virtual Server version 1.2.1 (size=4096)
Prot LocalAddress:Port Scheduler Flags
  -> RemoteAddress:Port           Forward Weight ActiveConn InActConn
TCP  172.16.0.100:80 wrr
  -> 10.0.0.7:80                  Route   1      0          0
  -> 10.0.0.17:80                 Route   1      0          0

9.client Test access

1. Access detection
[[email protected] ~]#while :;do curl 172.16.0.100;sleep 1;done
rs2 10.0.0.17
rs1 10.0.0.7
rs2 10.0.0.17
