Four software 2021-10-14 suitable for beginners to draw PCB

For painting PCB There are many kinds of board software , Novice painting pcb What software is better for the board , It's not a good choice for a beginner , Today I will recommend four kinds of paintings for beginners pcb Board software , This is also a painting commonly used by many engineers PCB Board software , The following is a brief analysis of these four software .

1、protel Software
protel Software is widely used by people in China , Few people use it abroad , It belongs to the mainstream of low-end design in China , Easy to learn , Easy to use , Suitable for beginners .protel The only bad thing about software is that it takes up a lot of system resources , High requirements for computer configuration .

2、PADS Software
PADS The software is suitable for medium and low-end design , Than protel The software is easy to use , Easy to use , It can be called the uncrowned king in the low end .

3、CAM350 Software
Many companies' later projects use CAM350 Software to confirm the , So for the use of CAM350 Software companies , The customer had better directly provide CAM350 The file of , This will reduce the problems in the process of guiding later .

4、AD Software
AD Mainly original Protel Software developers Altium The company launched an integrated electronic product development system , Running on the Windows XP、Windows7 operating system .AD The software designs the schematic diagram 、 Circuit simulation 、PCB Drawing, editing 、 Topology logic auto routing 、 Perfect integration of signal integrity analysis and design output technology , It provides a new design solution for designers , Make it easy for designers to design , Skillful use of this software will greatly improve the quality and efficiency of circuit design .

protel Software 、PADS Software 、CAM350 Software is easy to learn , Easy to use , Suitable for beginners , If you can use it skillfully , Can greatly improve their own painting PCB The ability of the board .

For painting PCB What software does the board use , Through the above simple explanation , I believe that beginners should have a general understanding .

Want to know more about it , You can pay attention to me ！PCB Design -PCB Board making -SMT Patch -BOM Match the order
