Flame framework - Flame WTF form: file upload, verification code
2022-07-25 10:53:00 【White chocolate Lin】
Catalog
In the last article , We learned Flask frame ——Flask-WTF Forms ： data validation 、CSRF Protect , This article is for us to learn Flask frame ——Flask-WTF Forms ： Upload files 、 Verification Code .
Upload files
Flask-WTF The form provides FileField Field to handle file upload , After the form is submitted , Automatically from flask.request.files Extract data from .
The sample code is as follows ：
import os
from flask import Flask, render_template
from flask_wtf import FlaskForm, CSRFProtect
from flask_wtf.file import FileField, FileRequired, FileAllowed
app = Flask(__name__)
app.config['SECRET_KEY']='hakhfaskh' # To configure CSRF The key needed , Its value is arbitrary
csrf = CSRFProtect(app) # take CSRF Protection is added to app in
class Myform(FlaskForm):
file = FileField(label=' Upload the user's Avatar ',validators=[FileRequired(), FileAllowed(['jpg','png'])]) # establish FileField Field
@app.route('/',methods=['GET','POST'])
def hello_world():
myform = Myform() # Create a form object
if myform.validate_on_submit(): # Check whether it is a POST Request and whether the request is valid
filename=myform.file.data.filename # Get the passed in file name
filepath=os.path.dirname(os.path.abspath(__file__)) # Get the file path of the current project
savepath=os.path.join(filepath,'static') # Set save file path
myform.file.data.save(os.path.join(savepath,filename)) # Save the file
return ' Submit successfully '
return render_template('file.html', myform=myform) # Use render_template() Method rendering file.html Document and will myform Pass on to file.html in
if __name__ == '__main__':
app.run(debug=True)
To configure CSRF The required key and will CSRF Protection is added to app in , Then create a name called Myform Form class for , In the class, we define FileField File field and use FileRequired File validation functions and FileAllowed File type verification function .
Create a form class object in the view function , Used validate_on_submit() Method to check whether it is a POST Request and whether the request is valid , Get the passed in file name and define the path to save the file , Finally using render_template() Method rendering file.html Document and will myform Pass on to file.html in .
Create a file.html file , Its contents are as follows ：
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<title>Title</title>
</head>
<body>
<form action="{
{ url_for('hello_world') }}" method="post" enctype="multipart/form-data">
{
{ myform.csrf_token }} {# Rendering csrf#}
<p>{
{ myform.file.label }}{
{ myform.file }}</p>
<input type="submit" value=" Submit ">
</form>
</body>
</html>
Be careful ： Related to documents , Need to be in HTML Form enctype Set to multipart/form-data.
start-up flask project , visit http://127.0.0.1:5000/ And select the file , As shown in the figure below ：
Verification Code
Flask-WTF adopt RecaptchaField It also provides support for verification code , The sample code is as follows ：
from flask import Flask, render_template
from flask_wtf import FlaskForm, RecaptchaField, CSRFProtect
app = Flask(__name__)
app.config['SECRET_KEY']='hakhfaskh' # To configure CSRF The key needed , Its value is arbitrary
csrf = CSRFProtect(app) # take CSRF Protection is added to app in
class Myform(FlaskForm):
recaptcha = RecaptchaField() # Verification code field
@app.route('/')
def yanzm():
myform=Myform() # Create a form object
return render_template('yanzm.html', myform=myform) # Use render_template() Method rendering yanzm.html Document and will myform Pass on to file.html in
if __name__ == '__main__':
app.run()
To configure CSRF The required key and will CSRF Protection is added to app in , Create a Myform Form class for , In the class, we define RecaptchaField Verification code field , In the view function, we create the form object , Use render_template() Method rendering yanzm.html Document and will myform Pass on to file.html in .
The following parameters need to be configured to use the verification code ：
RECAPTCHA_PUBLIC_KEY： Mandatory , Public key ;
RECAPTCHA_PRIVATE_KEY： Mandatory , Private key ;
RECAPTCHA_API_SERVER： Optional , Verification Code API The server ;
RECAPTCHA_PARAMETERS： Optional , One JavaScript（api.js） Dictionary of parameters ;
RECAPTCHA_DATA_ATTRS： Optional , A list of data attribute items https://developers.google.com/recaptcha/docs/display.
Create a yanzm.html, Its contents are as follows ：
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<title>Title</title>
</head>
<body>
<form action="/" method="post">
{
{ myform.csrf_token }}
{
{ myform.recaptcha }}
</form>
</body>
</html>
start-up flask project , visit http://127.0.0.1:5000/, Found nothing to show , This is because RecaptchaField() Field needs to call Google's verification code API, And call Google's verification code API Need to climb over the wall , We didn't climb over the wall , So nothing shows , As shown in the figure below ：
Use RecaptchaField() The verification code field needs to cross the wall , Then we won't use it , We draw the verification code ourselves .
Here we draw the verification code using pillow Graphics library , It executes the following code installation ：
pip install pillow
Install well pillow after , Let's create a name uitl.py file , Its function is to draw our graphic verification code , The code is as follows ：
import random
from PIL import Image, ImageFont, ImageDraw
# Customize get_color Method , Get three random numbers and save them in tuples
def get_color():
return (random.randint(0,255),random.randint(0,255),random.randint(0,255))
# Customize generate_image Method to draw a picture verification code
def generate_image(4):
size=(130,50) # Set the size of the verification code
im=Image.new('RGB',size,color=get_random_color()) # Create a verification code background
font=ImageFont.truetype('C:\Windows\Fonts/simsun.ttc',size=40) # Set verification code font
draw=ImageDraw.Draw(im) # establish ImageDraw object
code='' # Set the verification code value
s='abcdefghijklmnopqrstuvwxyz123456' # Set the value range of the verification code
for i in range(4): # draw 4 Digit verification code value
c=random.choice(s) # Random in s The value of
code+=c # Put the obtained value in the verification code
draw.text((9+random.randint(4,7)+20*i,random.randint(4,7)),text=c,fill=get_random_color(),font=font) # Write the verification code value in the verification code background
im.show()
return im ,code # Return the image and verification code value
We customize get_color Method gets a three bit random number stored in a tuple and returns , Customize it again generate_image() Method to draw a picture verification code , Set the value range of the verification code 、 Background image size font, etc , And randomly obtain the verification code value and write it into the verification code background .
You can do it according to pillow Library documentation to add some interference lines to the verification code , In this way, the simple version of the graphic verification code is made , As shown in the figure below ：
Here we draw 4 Character image verification code , The code generation of image verification code has been written , Next we write flask Project to use the verification code , The sample code is as follows ：
from flask import Flask, render_template, session
from flask_wtf import FlaskForm, CSRFProtect
from wtforms import StringField, ValidationError
app = Flask(__name__)
app.config['SECRET_KEY']='hakhfaskh' # To configure CSRF The key needed , Its value is arbitrary
csrf = CSRFProtect(app) # take CSRF Protection is added to app in
class Myform(FlaskForm): # Create a form class
recaptcha = StringField() # Create a text field
def validate_recaptcha(self, data): # Custom validation
input_code=data.data # The value of the entered verification code
code=session.get('valid') # obtain session Of valid value
if input_code.lower()!=code.lower(): # Convert the verification code value to lowercase and judge whether the input verification code and the image verification code value are consistent
raise ValidationError(' Verification code error ') # Throw an error
@app.route('/',methods=['GET','POST'])
def yanzm():
myform=Myform() # Create form class objects
if myform.validate_on_submit(): # Check whether it is a POST Request and whether the request is valid
return ' Verify success '
return render_template('yanzm.html', myform=myform) # Use render_template() Method rendering yanzm.html Document and will myform Pass on to file.html in
if __name__ == '__main__':
app.run()
Set up CSRF Protect , Create a form class to use StringField() Text fields and custom validation functions , Then create a form class object in the view function , Use validate_on_submit() Method to check whether it is a POST Request and whether the request is valid , Use render_template() Method rendering yanzm.html Document and will myform Pass on to file.html in .
Is this ok ？ Here we also need to create a view function to get the image verification code , The code is as follows ：
from util import generate_image # Import generate_image
@app.route('/image')
def get_image():
im,code=generate_image() # Get the verification code image and value
buffer=BytesIO() # take image Object to binary
im.save(buffer,"JPEG") # Save in binary form as JPEG Format
buf_bytes=buffer.getvalue() # Read binary verification code
session['valid']=code # Save to session in , Control the expiration time of the verification code
response=make_response(buf_bytes) # structure response object
response.headers['Content-Type']='image/jpg' # Custom request header
return response
In the view function , We call generate_image() Method to obtain the verification code image and value and save the image in binary form as JPEG Format , Generally, the verification code has an expiration time , So we use session Control the implementation time of the verification code , Use make_response() structure response Object to customize the request header for the verification code image .
Next we write yanzm.html file , The code is as follows ：
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<title>Title</title>
</head>
<body>
<form action="/" method="post">
{
{ myform.csrf_token }} {# Rendering csrf#}
{
{ myform.recaptcha }}<img src="{
{ url_for('get_image') }}" alt="" id="img">
<p>{
{ myform.recaptcha.errors.0 }}</p>
<input type="submit" value=" Submit ">
</form>
</body>
</html>
In general , As long as we click the image verification code, it will refresh , So we can add the following code to control the refresh of the image verification code ：
<script src="http://libs.baidu.com/jquery/2.0.0/jquery.min.js"></script>
<script>
$('#img').click(function (){
$(this).attr('src',"{
{ url_for('get_image') }}?ran="+Math.random());
})
</script>
Here we call Baidu jquery And add a click event for the verification code .
Okay , In this way, we have successfully drawn our image verification code , start-up flask project , visit http://127.0.0.1:5000/, As shown in the figure below ：
When we input correctly and click Submit , It will show that the verification is successful , When we input incorrectly and click Submit , The verification code error will be displayed .
Okay ,Flask frame ——Flask-WTF Forms ： Upload files 、 That's all for the verification code , Thank you for watching. , Next article study Flask frame ——Flask-Mail mail .
official account ： White chocolate LIN
The official account is released Python、 database 、Linux、Flask、 automated testing 、Git Etc ！
- END -
