华为无线设备配置WAPI-证书安全策略

1. 配置LSW和AC，使AP与AC之间能够传输CAPWAP报文
   [LSW1]vlan batch 100
   [LSW1-GigabitEthernet0/0/1]port link-type trunk
   [LSW1-GigabitEthernet0/0/1]port trunk allow-pass vlan 100
   [LSW1-GigabitEthernet0/0/2]port link-type trunk
   [LSW1-GigabitEthernet0/0/2]port trunk allow-pass vlan 100
   [LSW1-GigabitEthernet0/0/2]port trunk pvid vlan 100
   [LSW1-GigabitEthernet0/0/2]port-isolate enable
   [AC1]vlan batch 100
   [AC1-GigabitEthernet0/0/1]port link-type trunk
   [AC1-GigabitEthernet0/0/1]port trunk allow-pass vlan 100

2. 配置AC与上层网络设备互通
   [AC1]vlan batch 101 102 103
   [AC1-Vlanif101]ip add 10.1.101.1 24
   [AC1-Vlanif102]ip add 10.1.102.1 24
   [AC1-Vlanif103]ip add 10.1.103.1 24
   [AC1-GigabitEthernet0/0/2]port link-type access
   [AC1-GigabitEthernet0/0/2]port default vlan 102
   [AC1-GigabitEthernet0/0/3]port link-type trunk
   [AC1-GigabitEthernet0/0/3]port trunk allow-pass vlan 103
   [AC1-GigabitEthernet0/0/3]port trunk pvid vlan 103
   [AC1]ip route-static 0.0.0.0 0.0.0.0 10.1.102.2

3. 配置AC给AP分配IP地址，AR给STA分配IP地址
   [AC1]dhcp enable
   [AC1-Vlanif100]ip add 10.1.100.1 24
   [AC1-Vlanif100]dhcp select interface
   [AC1-Vlanif101]dhcp select relay
   [AC1-Vlanif101]dhcp relay server-ip 10.1.102.2
   [AR1]dhcp enable
   [AR1-ip-pool-sta]gateway-list 10.1.101.1
   [AR1-ip-pool-sta]dns-list 8.8.8.8
   [AR1-ip-pool-sta]network 10.1.101.0 mask 24
   [AR1-GigabitEthernet0/0/0]ip add 10.1.102.2 24
   [AR1-GigabitEthernet0/0/0]dhcp select global
   [AR1]ip route-static 10.1.101.0 24 10.23.102.1

4. 配置AP上线
   创建AP组
   [AC1]wlan
   [AC1-wlan-view]ap-group name ap-group1
   创建域管理模板，在域管理模板下配置AC的国家码并在AP组下引用域管理模板
   [AC1-wlan-view]regulatory-domain-profile name domain1
   [AC1-wlan-regulate-domain-domain1]country-code cn
   [AC1-wlan-view]ap-group name ap-group1
   [AC1-wlan-ap-group-ap-group1]regulatory-domain-profile domain1
   [AC1]capwap source interface Vlanif 100
   在AC上离线导入AP，并将AP加入AP组
   [AC1-wlan-view]ap auth-mode mac-auth
   [AC1-wlan-view]ap-id 0 ap-mac 00e0-fc19-7cf0
   [AC1-wlan-ap-0]ap-name ap1
   [AC1-wlan-ap-0]ap-group ap-group1


5. 配置WLAN业务参数
   创建安全模板，并配置安全策略
   [AC1]wlan
   [AC1-wlan-view]security-profile name wlan-security
   [AC1-wlan-sec-prof-wlan-security]security wapi certificate
   [AC1-wlan-sec-prof-wlan-security]wapi asu ip 10.1.103.2
   [AC1-wlan-sec-prof-wlan-security]wapi import certificate ac format pem file-name flash:/as.cer
   [AC1-wlan-sec-prof-wlan-security]wapi import certificate asu format pem file-name flash:/as.cer
   [AC1-wlan-sec-prof-wlan-security]wapi import certificate issuer format pem file-name flash:/as.cer
   [AC1-wlan-sec-prof-wlan-security]wapi import private-key format pem file-name flash:/ae.cer
   创建SSID模板，并配置SSID名称
   [AC1-wlan-view]ssid-profile name wlan-ssid
   [AC1-wlan-ssid-prof-wlan-ssid]ssid wlan-net
   创建VAP模板，配置业务数据转发模式、业务VLAN，并且引用安全模板、认证模板和SSID模板
   [AC1-wlan-view]vap-profile name wlan-vap
   [AC1-wlan-vap-prof-wlan-vap]forward-mode tunnel
   [AC1-wlan-vap-prof-wlan-vap]service-vlan vlan-id 101
   [AC1-wlan-vap-prof-wlan-vap]security-profile wlan-security
   [AC1-wlan-vap-prof-wlan-vap]ssid-profile wlan-ssid
   配置AP组引用VAP模板，AP上射频0和射频1都使用VAP模板的配置
   [AC1-wlan-view]ap-group name ap-group1
   [AC1-wlan-ap-group-ap-group1]vap-profile wlan-vap wlan 1 radio 0
   [AC1-wlan-ap-group-ap-group1]vap-profile wlan-vap wlan 1 radio 1

6. 配置AP射频的信道和功率
   关闭射频的信道和功率自动调优功能
   [AC1-wlan-view]rrm-profile name default
   [AC1-wlan-rrm-prof-default]calibrate auto-channel-select disable
   [AC1-wlan-rrm-prof-default]calibrate auto-txpower-select disable
   配置AP射频的信道和功率
   [AC1-wlan-view]ap-id 0
   [AC1-wlan-ap-0]radio 0
   [AC1-wlan-radio-0/0]channel 20mhz 6
   [AC1-wlan-radio-0/0]eirp 127
   [AC1-wlan-ap-0]radio 1
   [AC1-wlan-radio-0/1]channel 20mhz 149
   [AC1-wlan-radio-0/1]eirp 127
