How to set up the router correctly

One 、 equipment ： Buy a router , Such as TP-LINK（TL-R402M）90 yuan , There is one WAN Mouth and four LAN mouth , In addition, two net cables with crystal heads clamped at both ends .

Two 、 Connection method ： Plug the cable into the crystal head of the desktop （ The other end is connected ADSL Of ） Connect to the router WAN On the mouth , Connect the other two network cables to the four powered routers LAN Any two mouths in the mouth , In addition, both ends are inserted into two desktop network cards .

3、 ... and 、 Desktop settings ：1、 First delete the original dialing program , Right click IE browser – attribute – Connect , Select the dial number in the white box , Click delete , determine . If it's the star speed dialing installed with telecom , Then uninstall it .2、 Set desktop computers respectively IP, Right click on my network neighbor – attribute – Right click that one again “ Local connection ”– attribute – Click on Internet agreement （TCP/IP）– Click on “ attribute ” Button , Fill in

IP：192.168.1.111 （ or ）192.168.1.*（* representative 2-100 A number between , It can't be filled in 1 Otherwise, it conflicts with the router itself ）

Subnet mask ：255.255.255.0

gateway ：192.168.1.1

DNS： Given by telecommunications DNS( Different regions DNS Different , Call Telecom ） Call the network service provider for specific values , For example, Netcom , Just fight 10060, Just consult the artificial desk … （ Or directly the gateway ip 192.168.1.1 that will do ）

Click OK twice after setting . The other one is also set ,IP It's just different , Such as 192.168.1.222.

Add ： It can also be 192.168.0.*

Subnet mask ：255.255.255.0

gateway ：192.168.0.1 dns You can also fill in 192.168.0.1

Four 、 Router settings ： Double click on any desktop IE browser , Enter... In the address field 192.168.1.1, Log in to the router , Enter the password for the user name ： The default is admin（ or ）guest ( If not, please check the router manual ）. Click on “ Setup wizard ”, next step , choose “ADSL Virtual dialing （PPPoE）” The most important thing is to set the dialing method to （pppoe） . next step , Fill in the online account and password , Is the user name and password used when dialing , Click finish . Don't set the others , Just use the default .

After the above steps , You don't need to dial when starting up , Go online directly .

The above settings are based on “TP-LINK（TL-R402M） Or gateway is 192.168.1.1” Take the router of as an example , Different router settings are different , The parameters of desktops and routers cannot be copied as above , But it's the same , For details, please follow the instructions of the router .

（ attach ）：

Crystal head net cable ： Linear sequence （ White orange . orange . White and green . blue . White and blue . green . White brown . Brown ）

=====================================

Take alpha for example …

Alpha Internet broadband router
alpha AFR-K3 Internet broadband router
performance ： High speed stability ： Fast computing power , Stable performance
Convenient and simple ： All Chinese quick configuration wizard and the whole process “ help ” Information
Flexible and practical ： Flexible timing control , Support access control , Support DMZ host
Safe and reliable ： Firewall and message filtering , Support WAN Traffic statistics
Restrict web applications ： Specific network applications in the LAN can be shielded through the shielding port , Such as QQ etc.
It can be authorized separately for each computer ： According to the MAC Address , Conduct independent access authorization
Support static routing and dynamic routing
The built-in NAT Firewall protects LAN
Support DMZ, Can support IP Multimedia applications such as telephone video conferencing, online games `
Built in Chinese WEB The server , Humanized interface design is friendly, concise and easy to install
1 individual 10M-100M Ethernet （WAN） Interface , Connectable XDSL or Cable Modem Or Ethernet .4 individual

10M-100M Ethernet （LAN） Interface . Support Auto-MDI-MDIX Auto flip . Shielding port can shield

Specific network applications within the LAN , Provide flow monitoring , And view the websites visited by users , The built-in NAT Fire prevention

The wall protects the LAN , Support DMZ, Support DHCP The server , Built in Chinese WEB The server .
