Stm32f103c8t6 realize breathing lamp code

PWM.h

#ifndef __PWM_H
#define __PWM_H

void PWM_Init();
void PWM_SetCompare1(uint16_t Compare);

#endif

PWM.c

#include "stm32f10x.h" // Device header

void PWM_Init()
{

	RCC_APB1PeriphClockCmd(RCC_APB1Periph_TIM2,ENABLE);  // Turn on timer 2
	RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOA,ENABLE);// passageway 2 Clock enable function

	GPIO_InitTypeDef GPIO_InitStructure; 				// Definition GPIO Initializing structure variables
	GPIO_InitStructure.GPIO_Mode = GPIO_Mode_AF_PP;	// Set up GPIO For push-pull output mode
	GPIO_InitStructure.GPIO_Pin = GPIO_Pin_0;			// Set up  P1 P2
	GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;	// The speed is set to  50MHz
	GPIO_Init(GPIOA, &GPIO_InitStructure);				// Proceed according to the above parameters  GPIO The initialization

	TIM_InternalClockConfig(TIM2);//TIM The time base unit of is controlled by the internal clock

	TIM_TimeBaseInitTypeDef TIM_TimeBaseInitStructure;
	TIM_TimeBaseInitStructure.TIM_ClockDivision = TIM_CKD_DIV1;
	TIM_TimeBaseInitStructure.TIM_CounterMode = TIM_CounterMode_Up;
	TIM_TimeBaseInitStructure.TIM_Period = 100 - 1; //ARR  The value of the automatic reloader
	TIM_TimeBaseInitStructure.TIM_Prescaler = 720 - 1; //PSC  Prescaler value   Yes 72M（720000000） Conduct  7200 frequency division   namely 10K At different frequencies   meter 10000 Number  1s Time for
	TIM_TimeBaseInitStructure.TIM_RepetitionCounter = 0;// Repeat counter value
	TIM_TimeBaseInit(TIM2,&TIM_TimeBaseInitStructure);

	TIM_OCInitTypeDef TIM_OCInitStructure;
	TIM_OCStructInit(&TIM_OCInitStructure);
	TIM_OCInitStructure.TIM_OCMode = TIM_OCMode_PWM1;
	TIM_OCInitStructure.TIM_OCPolarity = TIM_OCPolarity_High;// Output polarity selection
	TIM_OCInitStructure.TIM_OutputState = TIM_OutputState_Enable;// Output status enable
	TIM_OCInitStructure.TIM_Pulse = 10;//CCR
	TIM_OC1Init(TIM2,&TIM_OCInitStructure);


	TIM_Cmd(TIM2,ENABLE);
}


void PWM_SetCompare1(uint16_t Compare)// Constant adjustment CCR, Achieve breathing lamp effect
{

	TIM_SetCompare1(TIM2, Compare);
}

main.c

#include "stm32f10x.h" // Device header
#include "Delay.h"
#include "LED.h"
#include "Key.h"
#include "OLED.H"
#include "PWM.H"

uint8_t i;

int main(void)
{

	OLED_Init();
	PWM_Init();

	while (1)
	{

		for ( i = 0; i <= 100; i++)
		{

			PWM_SetCompare1(i);
			Delay_ms(10);// Delay , Otherwise it will be too fast
		}
		for ( i = 0; i <= 100; i++)
		{

			PWM_SetCompare1(100 - i);
			Delay_ms(10);
		}
	}
}
