Unity3d+moba+ skill indicator (II)

2.3 Indicator picture highlights shader

newly build shader, The code is as follows

Shader "Custom/SkillHintBg" {
Properties {
	_MainTex ("Base Texture", 2D) = "white" {}
	_Color ("Main Color", Color) = (1,1,1,1)
}

Category {
	Tags { "Queue"="Transparent" "IgnoreProjector"="True" "RenderType"="Transparent" }
	Blend SrcAlpha OneMinusSrcAlpha
	Cull Off
	Lighting Off
	ZWrite Off

	BindChannels {
		Bind "Color", color
		Bind "Vertex", vertex
		Bind "TexCoord", texcoord
	}

	SubShader {
		Pass {
		//ZTest Always
			CGPROGRAM
				#pragma vertex vert
				#pragma fragment frag

				#include "UnityCG.cginc"

				struct v2f {
					float4 pos : SV_POSITION;
					float2 uv : TEXCOORD0;
				};

				v2f vert(appdata_tan v)
				{
					v2f o;
					o.pos = mul (UNITY_MATRIX_MVP, v.vertex);
					o.uv = v.texcoord;
					return o;
				}

				sampler2D _MainTex;
				float4 _Color;

				half4 frag (v2f i) : COLOR
				{
					half4 result = tex2D (_MainTex, i.uv);
					result*=_Color;
					return result;
				}
			ENDCG
		}
		Pass {
		ZTest Greater
			CGPROGRAM
				#pragma vertex vert
				#pragma fragment frag

				#include "UnityCG.cginc"

				struct v2f {
					float4 pos : SV_POSITION;
					float2 uv : TEXCOORD0;
				};
				v2f vert(appdata_tan v)
				{
					v2f o;
					o.pos = mul (UNITY_MATRIX_MVP, v.vertex);
					o.uv = v.texcoord;
					return o;
				}

				sampler2D _MainTex;
				float4 _Color;

				half4 frag (v2f i) : COLOR
				{
					half4 result = tex2D (_MainTex, i.uv);
					result*=_Color;
					result.a /= 3;
					return result;
				}
			ENDCG
		}
	}
}
}

Originally used shader

Effect of formation

Use highlight shader after

2.4 Sector range indicator

Here is to dynamically generate a sector mesh, Achieve the effect to be displayed by setting the angle and radius . Dynamically generate sectors mesh The code is as follows ：

using UnityEngine;
using System.Collections;

[RequireComponent(typeof(MeshRenderer), typeof(MeshFilter))]
public class MeshFan : MonoBehaviour
{
    public float radius = 2;
    public float angleDegree = 100;
    public int segments = 10;
    public int angleDegreePrecision = 1000;
    public int radiusPrecision = 1000;

    private MeshFilter meshFilter;

    private SectorMeshCreator creator = new SectorMeshCreator();
    private Mesh m_mesh;
    [ExecuteInEditMode]
    private void Awake()
    {
        meshFilter = GetComponent<MeshFilter>();
    }

    private void Update()
    {
        meshFilter.mesh = creator.CreateMesh(radius, angleDegree, segments, angleDegreePrecision, radiusPrecision);
    }

    void OnDrawGizmos()
    {
        Gizmos.color = Color.gray;
        DrawMesh();
    }

    void OnDrawGizmosSelected()
    {
        Gizmos.color = Color.green;
        DrawMesh();
    }

    private void DrawMesh()
    {
        Mesh mesh = creator.CreateMesh(radius, angleDegree, segments, angleDegreePrecision, radiusPrecision);
        int[] tris = mesh.triangles;
        for (int i = 0; i < tris.Length; i += 3)
        {
            Gizmos.DrawLine(convert2World(mesh.vertices[tris[i]]), convert2World(mesh.vertices[tris[i + 1]]));
            Gizmos.DrawLine(convert2World(mesh.vertices[tris[i]]), convert2World(mesh.vertices[tris[i + 2]]));
            Gizmos.DrawLine(convert2World(mesh.vertices[tris[i + 1]]), convert2World(mesh.vertices[tris[i + 2]]));
        }
    }

    private Vector3 convert2World(Vector3 src)
    {
        return transform.TransformPoint(src);
    }

    private class SectorMeshCreator
    {
        private float radius;
        private float angleDegree;
        private int segments;

        private Mesh cacheMesh;

        /// <summary>
        ///  Create a sector Mesh
        /// </summary>
        /// <param name="radius"> Fan half price </param>
        /// <param name="angleDegree"> Fan angle </param>
        /// <param name="segments"> Segment number of sector arc </param>
        /// <param name="angleDegreePrecision"> Sector angle accuracy （ Within the accuracy range , Think it's the same angle ）</param>
        /// <param name="radiusPrecision">
        /// <pre>
        ///  Sector half price accuracy （ Within the range of half price accuracy , It is considered to be the same half price ）.
        ///  such as ： The half price accuracy is 1000, be ：1.001 and 1.002 It is not considered the same radius . Because zoom in 1000 Times are not equal .
        ///  If the half price precision is set to 100, be 1.001 and 1.002 Can be considered equal .
        /// </pre>
        /// </param>
        /// <returns></returns>
        public Mesh CreateMesh(float radius, float angleDegree, int segments, int angleDegreePrecision, int radiusPrecision)
        {
            if (checkDiff(radius, angleDegree, segments, angleDegreePrecision, radiusPrecision))
            {
                Mesh newMesh = Create(radius, angleDegree, segments);
                if (newMesh != null)
                {
                    cacheMesh = newMesh;
                    this.radius = radius;
                    this.angleDegree = angleDegree;
                    this.segments = segments;
                }
            }
            return cacheMesh;
        }

        private Mesh Create(float radius, float angleDegree, int segments)
        {

            if (segments == 0)
            {
                segments = 1;
#if UNITY_EDITOR
                Debug.Log("segments must be larger than zero.");
#endif
            }

            Mesh mesh = new Mesh();
            Vector3[] vertices = new Vector3[3 + segments - 1];// All vertex data
            vertices[0] = new Vector3(0, 0, 0);

            float angle = Mathf.Deg2Rad * angleDegree;
            float currAngle = angle / 2;
            float deltaAngle = angle / segments;

            currAngle = Mathf.Deg2Rad * (90 + angleDegree / 2);

            // Generate vertex data
            for (int i = 1; i < vertices.Length; i++)
            {
                vertices[i] = new Vector3(Mathf.Cos(currAngle) * radius, 0, Mathf.Sin(currAngle) * radius);
                currAngle -= deltaAngle;
            }

            // Generate triangle data
            int[] triangles = new int[segments * 3];// Yes segments Triangles , Every time 3 Data form a triangle
            for (int i = 0, vi = 1; i < triangles.Length; i += 3, vi++)
            {
                triangles[i] = 0;
                triangles[i + 1] = vi;
                triangles[i + 2] = vi + 1;
            }

            mesh.vertices = vertices;
            mesh.triangles = triangles;

            // Texture coordinates
            Vector2[] uvs = new Vector2[vertices.Length];
            for (int i = 0; i < uvs.Length; i++)
            {
                uvs[i] = new Vector2(vertices[i].x, vertices[i].z);
            }
            mesh.uv = uvs;

            return mesh;
        }
        private bool checkDiff(float radius, float angleDegree, int segments, int angleDegreePrecision, int radiusPrecision)
        {
            return segments != this.segments || (int)((angleDegree - this.angleDegree) * angleDegreePrecision) != 0 ||
                   (int)((radius - this.radius) * radiusPrecision) != 0;
        }
    }
}

Mesh : Grid components , It is mainly used to set the shape and appearance .3d Models are made of N Triangle formation , and mesh It is a collection of description information , establish mesh grid : It should be in the following order :1) Assign vertices 2) Assign triangles .

As shown in the figure ：

Generate a sector Mesh, from 10 Three small triangles form . The total number of vertices is 12. The first 0 The coordinates of the two vertices are （0,0,0）, And then to z The axis is positive , Calculate the coordinates of each fixed point in turn .

// Generate vertex data
            for (int i = 1; i < vertices.Length; i++)
            {
                vertices[i] = new Vector3(Mathf.Cos(currAngle) * radius, 0, Mathf.Sin(currAngle) * radius);
                currAngle -= deltaAngle;
            }

With all the vertex coordinates , Assign triangles .mesh.triangles For one int[], The quantity must be 3 Multiple , Every time 3 One for a group , Each value is from index number to mesh.vertices Find the corresponding coordinate data in .

// Generate triangle data
            int[] triangles = new int[segments * 3];// Yes segments Triangles , Every time 3 Data form a triangle
            for (int i = 0, vi = 1; i < triangles.Length; i += 3, vi++)
            {
                triangles[i] = 0;
                triangles[i + 1] = vi;
                triangles[i + 2] = vi + 1;
            }

Finally, set the fan according to the casting distance and influence radius of the skill mesh Parameters .

2.5 Selective skill indicator

This kind is the same as the fan , There is no need to set the degree , Use a default selection degree , for example 60 degree . When there is 1 Enemies in this choice sector 60 Within degrees , He is the target . If there are multiple enemies in range , Select the one closest to the included angle of the central ray . As shown in the figure ：

1. When there is no enemy in the sector of the selection indicator

2. When there is an enemy in the sector of the selection indicator , The selected enemy has a red column on his head （ Later use the light of God to do ）

3. When there are multiple enemies in the selection range , Select the one closest to the central ray

The code is as follows ：

/// <summary>
    ///  Select the prompt
    /// </summary>
    /// <param name="skill"></param>
    /// <param name="obj"></param>
    public UnitCtrl tarSelect(SkillCtrl skill,GameObject obj)
    {
        UnitCtrl unitSelect = null;
        float fRadius = 0.0f;
        fRadius = skill.m_disRange;// Skill radius
        Vector3 pos = transform.position;
        Collider[] bufCollider = Physics.OverlapSphere(pos, fRadius);// Get surrounding members
        List<UnitCtrl> listUnit = new List<UnitCtrl>();
        foreach (var item in bufCollider)
        {
            UnitCtrl unit = item.GetComponentInParent<UnitCtrl>();
            if (unit != null)
            {
                if (!MainMgr.self.isWe(unit.m_camp) && unit.isAlive && unit.m_isVisible)// Not our party , Alive , so
                {
                    listUnit.Add(unit);
                }
            }
        }

        float minDegree = m_selectDegree/2.0f;
        // Screen again within the large circle   1. Meet the included angle of the selection range ,2. The angle from the center ray is the smallest
        foreach (var unit in listUnit)
        {
            Vector3 unitVec = unit.transform.position - obj.transform.position;
            Vector3 selectVec = obj.transform.forward;
            float degree = Vector3.Angle(unitVec, selectVec);
            if (degree <= minDegree)
            {
                minDegree = degree;
                unitSelect = unit;
            }
        }

        if (unitSelect != null)
        {
            UIMgr.self.headLockSet(true, unitSelect);
        }
        else
        {
            UIMgr.self.headLockSet(false, unitSelect);
        }
        return unitSelect;
}

Among them, we should pay attention to the selected red column , There can only be one in the scene （ Selected skills can only attack one person at a time ）, When I have a choice of goals , Set the parent node of the red column as the target （ Achieve red pillar to follow the target within the selection range ）, When I don't exist, choose a goal , The red column is not activated , And put it back pool In the child nodes of the pool . The code is as follows ：

public void headLockSet(bool active,UnitCtrl unit)
    {
        m_headLock.SetActive(active);
        if (active == true)
        {
            m_headLock.transform.SetParent(unit.transform);
            m_headLock.transform.localPosition = new Vector3(0,10,0);
            Renderer hintRenderer = m_headLock.GetComponent<Renderer>();
            hintRenderer.material.SetColor("_Color", Color.red);
        }
        else
        {
            m_headLock.transform.SetParent(m_prefab.transform);
            m_headLock.transform.localPosition = new Vector3(0, 0, 0);
        }
    }
