Sichuan earth microelectronics ca-is1300 isolated operational amplifier for current detection is on the market

Chuantu microelectronics CA-IS1300G25G Isolated operational amplifier for current detection New products are coming ！

01 Product overview

CA-IS1300 It is a high-precision isolated operational amplifier optimized for current detection based on shunt resistance . Low offset and gain errors and associated temperature drift can maintain measurement accuracy over the full operating temperature range .

The device uses silicon dioxide （SiO2） As a barrier , Support compliance UL1577 Certified up to 5 kVRMS Electrical isolation of . This technology separates the high and low voltage regions to prevent the devices in the low voltage region from being damaged , At the same time, it provides low radiation and high magnetic field immunity . High common mode transient immunity （CMTI） signify CA-IS1300 The device transmits signals correctly between the isolation layers , Suitable for high voltage 、 Industrial motor control and drive applications of high-power switches . The device internal input common mode overvoltage protection and high side power loss detection functions are helpful for fault diagnosis and system safety .



02 Product characteristics

• Differential input voltage range ：±250 mV

• Fixed initial gain ：8.2

• Low input offset and temperature drift ：25°C when ±1mV（ Maximum ）,±4 μV/°C（ Maximum ）

• Low gain error and temperature drift ：25°C when ±0.5%（ Maximum ）,±50 ppm/°C（ Maximum ）

• Low Nonlinearity and temperature drift ： Within rated range 0.01%（ Typical values ）,±1 ppm/°C（ Typical values ）

• Both high and low sides support 3.3 V and 5 V Supply voltage

• High common mode transient immunity ：±150 kV/µs（ Typical values ）

•  Wide operating temperature range ：–40°C To 125°C

• The service life under rated working voltage is longer than 40 year

• Package form ：SOIC8-WB（G）



Up to now , Sichuan earth microelectronic isolation op amp series products are gradually improving , among CA-IS1200U Delivered in batches ,CA-IS1200G/1300G25G Samples are available today ！

CA-IS1200/1300 Selection table of isolated operational amplifier for current detection

All data are only for reference during preliminary model selection , Please refer to the product manual for formal model selection .
