[kernel] platform bus model for driving development and learning

One 、 Preface

The platform bus model is also handed over platform Bus model , He is Linux A virtual bus , He is not a real electrical bus ; The platform bus model is the original driver C The file is divided into two files. One is device The file corresponds to our device file , One is driver The file corresponds to our driver file , The advantages of platform bus are ：
1） Improve code reuse
2） Reduce repetitive code
3） Distinguish between equipment and drive
4） It is more convenient to manage our equipment
Put the stable drive on driver Inside , The equipment that needs to be changed is placed in device In file ; When we register device perhaps driver Will pass when name Match , In fact, it is the comparison of a string variable in the structure .

Two 、 register Device file

device.c Hardware resources are stored in the file , The hardware resource here refers to the register address 、 Interrupt number 、 Clock and other hardware resources , stay Linux In the kernel, we use a structure to describe ;

#include <linux/platform_device.h> // Header files required by platform devices

struct platform_device {

	const char	*name; //  Name required for platform bus matching
	int		id; //  Number the same equipment , If there is only one equipment here -1 that will do
	bool		id_auto;
	struct device	dev; //  embedded device Structure
	u32		num_resources; //  Number of resources ARRAY_SIZE(struct resource)
	struct resource	*resource;  // device Corresponding hardware resources ： Register address 、 Interrupt number, etc

	const struct platform_device_id	*id_entry;
	char *driver_override; /* Driver name to force a match */
	/* MFD cell pointer */
	struct mfd_cell *mfd_cell;
	/* arch specific additions */
	struct pdev_archdata	archdata;
};

Device resource structure

struct resource {

	resource_size_t start; //  Register start address
	resource_size_t end; //  Register end address
	const char *name; //  Resource name
	unsigned long flags; //  The resource type
	unsigned long desc;
	struct resource *parent, *sibling, *child;

	ANDROID_KABI_RESERVE(1);
	ANDROID_KABI_RESERVE(2);
	ANDROID_KABI_RESERVE(3);
	ANDROID_KABI_RESERVE(4);
};

Resource types include ：

#define IORESOURCE_TYPE_BITS 0x00001f00 /* Resource type */
#define IORESOURCE_IO 0x00000100 /* PCI/ISA I/O ports */ // io Of memory
#define IORESOURCE_MEM 0x00000200 //  Physical memory address  （ Commonly used ）
#define IORESOURCE_REG 0x00000300 /* Register offsets */
#define IORESOURCE_IRQ 0x00000400 //  Interrupt number  （ Commonly used ）
#define IORESOURCE_DMA 0x00000800 // DMA The address of
#define IORESOURCE_BUS 0x00001000 //  Bus number ：SPI 、 IIC

Example

//  Equipment resource information , That is to say  BEEP  All registers used
struct resource led_res[] = {

    [0] = {

        .start = 0xfdd60000,  //  Corresponding start address
        .end = 0xfdd60003, //  Corresponding end address
        .flags = IORESOURCE_MEM,  //  Express GPIO Memory
        .name = "GPIO_DR",  //  Express DR Register random
        }
    [1] = {

        .start = 0xffffff0,  //  Corresponding to the starting address used by the second driver
        .end = 0xfffffff, //  Corresponding to the end address used by the second driver
        .flags = IORESOURCE_IO,  //  Express GPIO Memory
        .name = "GPIOA7",  //  Express DR Register random
       }
};

// platform  Equipment structure
struct platform_device led_device = {

    .name = "led_work",//  Drive matching name
    .id = -1,
    .resource = led_res, //  Fill in the device resource structure
    .num_resources = ARRAY_SIZE(led_res), //  Get the number of resources
    .dev = {

        .release = led_release
    } // device Device interface
};

platform Functions used for bus registration and unloading

platform_device_register(&led_device); //  register
platform_device_unregister(&led_device); //  uninstall

When we put the above device After registering to the kernel, in the development board /sys/bus/platform/devices Generate our led_work node

3、 ... and 、 register Driver file

To write driver The idea of , So let's define a platform_driver Variable , Then implement each member variable in the structure , When our driver perhaps device When registering, it will match name When the match is successful, it will execute probe function , So our driver The focus is on writing probe function , In this section, we will write driver Framework ;

struct platform_device_id led_id_table = {

    .name = "led_work", //  Matching priority is higher , If he fails to match, he will fail directly
};

// platform  Drive structure
struct platform_driver led_driver = {

	.probe = led_probe, //  Call after the device is successfully matched with the driver
	.remove = led_remove, //  Call after the driver is removed
	.driver={

		.owner = THIS_MODULE,
		.name = "led_work" //  Device matching name
	},
	//  adopt platform The equipment ID Match （ Higher priority , Use this matching method to match driver Of name Property will be invalid ）
	.id_table = &led_idtable
};

Bus driver registration and unloading functions

platform_driver_register(&led_driver);
platform_driver_unregister(&led_driver);

Four 、 To write Probe function

When our device is successfully matched with the driver, our driver can obtain the resource data in the device through functions , Then we can use this data to operate the device , For example, the registration of character devices 、 Registration of miscellaneous equipment 、SPI Use of resources 、IIC Use of equipment 、 Use of interrupts, etc ;

struct resource *led_mem;
int led_probe(struct platform_device *pdev)
{

    int ret;
    //  Get the number of memory address types of this function 0 A resource  , If there are multiple resources increasing in turn , If there is a resource of other types in the middle, it will not be counted
		//  for example
		// [0] IORESOURCE_MEM [1]IORESOURCE_IRQ [2]IORESOURCE_MEM
		//  If we want to get the following [2] resources ：platform_get_resource(pdev, IORESOURCE_MEM, 1)
		//  If we want to get the following [1] resources ：platform_get_resource(pdev, IORESOURCE_IRQ, 0)
    led_mem = platform_get_resource(pdev, IORESOURCE_MEM, 0);
    if (led_mem == NULL)
    {

        printk("platform_get_resource is error\n");
        return -EBUSY;
    }
    //  When our resources are successfully obtained, we accept the returned mem Is equal to device As defined in resource, We can use it directly
    printk("led_res start is 0x%x \n", led_mem->start);
    printk("led_res end is 0x%x \n", led_mem->end);
    return 0;
}

5、 ... and 、 Complete code example

Drive part

sdevices.c

#include <linux/init.h> // Initialize header file
#include <linux/module.h> // The most basic file , Support dynamic adding and unloading modules
#include <linux/platform_device.h>// Header files required by platform devices
#include <linux/mod_devicetable.h>
// #include <linux/gpio.h>

void led_release(struct device *dev)
{

    printk("led_release \n");
}

//  Equipment resource information , That is to say  BEEP  All registers used
struct resource led_res[] = {

    [0] = {

        .start = 0xfdd60000,
        .end = 0xfdd60003 ,
        .flags = IORESOURCE_MEM,
        .name = "led_work",
        }
};

// platform  Equipment structure
struct platform_device led_device = {

    .name = "led_work",
    .id = -1,
    .resource = led_res,
    .num_resources = ARRAY_SIZE(led_res),
    .dev = {

        .release = led_release
    }
};

static int device_init(void) {

    //  Device information is registered to  Linux  kernel
    platform_device_register(&led_device);
    return 0;
}

static void device_exit(void) {

    //  Device information uninstall
    platform_device_unregister(&led_device);
}

module_init(device_init);
module_exit(device_exit);
MODULE_LICENSE("GPL");

sdrivers.c

#include <linux/init.h> // Initialize header file
#include <linux/module.h> // The most basic file , Support dynamic adding and unloading modules
#include <linux/platform_device.h>// Header files required by platform devices
#include <linux/mod_devicetable.h>
#include <linux/ioport.h> /* Register miscellaneous device header file */
#include <linux/miscdevice.h> // File system header file , Define file table structure （file,buffer_head,m_inode  etc. ）
#include <linux/fs.h> // Contains  copy_to_user、copy_from_user  Wait for the kernel to access the function definition of the memory address of the user process .
#include <linux/uaccess.h> // Contains  ioremap、iowrite  Wait for kernel access  IO  Definition of functions such as memory .
#include <linux/io.h> // Register address definition

#include <linux/gpio.h>

// The first address of the mapped virtual address
unsigned int *vir_gpio_dr;
struct resource *led_mem;

long misc_ioctl(struct file *files, unsigned int cmd, unsigned long arg)
{

	printk("cmd is %d,arg is %d \n",cmd,(unsigned int)(arg));
	switch(cmd)
	{

		case 0:
			{

				printk(KERN_INFO "LEDON \n");
				*vir_gpio_dr = 0x80008000;
				break;
			}

		case 1:
			{

				printk(KERN_INFO "LEDOFF\n");
				*vir_gpio_dr = 0x80000000;
				break;
			}
	}
    return 0; //  It must be added or an error will be reported  error: control reaches end of non-void function [-Werror=return-type]
}


struct file_operations misc_fops={
       // File operation set
	.owner = THIS_MODULE,
    .unlocked_ioctl = misc_ioctl,
};

struct miscdevice  misc_dev = {
         // Miscellaneous equipment structure
	.minor = MISC_DYNAMIC_MINOR,    // Secondary equipment number of dynamic application
	.name = "platform_misc",		    // The name of miscellaneous equipment is hello_misc
	.fops = &misc_fops,  			// File operation set
};


int led_remove(struct platform_device *pdev)
{

    iounmap(vir_gpio_dr);
    misc_deregister(&misc_dev);
    return 0;
}

int led_probe(struct platform_device *pdev)
{

    int ret;
    led_mem = platform_get_resource(pdev, IORESOURCE_MEM, 0);
    if (led_mem == NULL)
    {

        printk("platform_get_resource is error\n");
        return -EBUSY;
    }
    printk("led_res start is 0x%llx \n", led_mem->start);
    printk("led_res end is 0x%llx \n", led_mem->end);

    ret = misc_register(&misc_dev);
    if(ret<0)
	{

		printk("misc registe is error \n");
	}
	printk("misc registe is succeed \n");
    // Convert physical address to virtual address
	vir_gpio_dr = ioremap(led_mem->start,4);
	if(vir_gpio_dr == NULL)
	{

	printk("GPIO_DR ioremap is error \n");
	return EBUSY;
	}
	printk("GPIO_DR ioremap is ok \n");

    return 0;
}

struct platform_device_id led_id_table = {

    .name = "led_work", //  Matching priority is higher , If he fails to match, he will fail directly
};

struct platform_driver led_driver = {

    .probe = led_probe,
    .remove = led_remove,
    .driver={

        .owner = THIS_MODULE,
        .name = "led"
    },
    .id_table = &led_id_table,
};

static int led_driver_init(void)
{

    int ret = 0; // platform  Driver registered to  Linux  kernel
    ret = platform_driver_register(&led_driver);
    if(ret<0) {

        printk("platform_driver_register error \n");
    }
    printk("platform_driver_register ok \n");
    return 0;
}

static void led_driver_exit(void)
{

    // platform  Drive unload
    platform_driver_unregister(&led_driver);
}

module_init(led_driver_init);
module_exit(led_driver_exit);
MODULE_LICENSE("GPL");

makefile

obj-m += sdrivers.o //  The driver and the device are modified accordingly
KDIR =/home/topeet/Linux/02.sdk/rk356x_linux/kernel
PWD ?= $(shell pwd)
all:
	make -C  $(KDIR) M=$(PWD) modules modules ARCH=arm64 CROSS_COMPILE=aarch64-linux-gnu-
clean:
	rm -rf modules.order *.o workqueue.o  Module.symvers *.mod.c *.ko

Usage method : Part sequence

insmod sdrivers.ko
insmod sdevices.ko

Application part

#include <stdio.h>
#include <stdlib.h>
#include <sys/types.h>
#include <sys/stat.h>
#include <fcntl.h>
#include <unistd.h>
#include <sys/ioctl.h>

#define LEDON 1 //  According to the driven switch To write
#define LEDOFF 0

int main(int argc,char *argv[])
{

    int fd;
    // Open the device node
    fd = open("/dev/platform_misc",O_RDWR);
    if(fd < 0)
    {

        // Failed to open the device node
        perror("open error \n");
        return fd;
    }
    while(1)
    {

        ioctl(fd,LEDON,0);
        sleep(1);
        ioctl(fd,LEDOFF,0);
        sleep(1);
    }
    close(fd);
}

Experimental results ：LED Light flashing
