Unity used trilib plug-in under URP pipeline to load model material incorrectly

Currently in use Unity Most of the development projects have been used URP Render pipeline , however TriLib The default material of the loaded model is the material of the built-in rendering pipeline , This will cause the material to not display properly , The solution is as follows ：

1、 stay Assets Create a new one in the directory AssetLoaderOptions Of ScriptObejct file ： Here's the picture

2、 Create a new one UniversalRPMaterialMapper Of ScriptObejct file : Here's the picture

3、 Now you will get two files , Continue after confirmation

4、 Click on AssetLoaderOptions, choice Materials, take UniversalRPMaterialMapper Add files to Material Mappers in

5、 At this step, load the prepared model again, and the materials can be displayed normally .
But there will also be errors in Map Compression . Because this plug-in requires the width and height of the map to be 4 Multiple , If the standard is not met, an error will be reported , We can set it again , Here's the picture

stay Texture Choose not to compress , That's all right. .

6、 Load model , I use the following API , Loaded from hard disk
AssetLoader.LoadModelFromFile(path, null, LoadEndCallBack, null, null, parent, assetLoaderOptions);
path: route
LoadEndCallBack： Loading completed callback function
parent: The parent object GameObject type
assetLoaderOptions： Created above AssetLoaderOptions file , For convenience, I put Resources Under the folder , use Resources.Load<>()
function

The work environment ：
Unity2021.3.2f1c1
TriLib 2
