华为无线设备配置WAPI-证书安全策略



1. 配置LSW和AC，使AP与AC之间能够传输CAPWAP报文

[LSW1]vlan batch 100

[LSW1-GigabitEthernet0/0/1]port link-type trunk

[LSW1-GigabitEthernet0/0/1]port trunk allow-pass vlan 100

[LSW1-GigabitEthernet0/0/2]port link-type trunk

[LSW1-GigabitEthernet0/0/2]port trunk allow-pass vlan 100

[LSW1-GigabitEthernet0/0/2]port trunk pvid vlan 100

[LSW1-GigabitEthernet0/0/2]port-isolate enable

[AC1]vlan batch 100

[AC1-GigabitEthernet0/0/1]port link-type trunk

[AC1-GigabitEthernet0/0/1]port trunk allow-pass vlan 100

2. 配置AC与上层网络设备互通

[AC1]vlan batch 101 102 103

[AC1-Vlanif101]ip add 10.1.101.1 24

[AC1-Vlanif102]ip add 10.1.102.1 24

[AC1-Vlanif103]ip add 10.1.103.1 24

[AC1-GigabitEthernet0/0/2]port link-type access

[AC1-GigabitEthernet0/0/2]port default vlan 102

[AC1-GigabitEthernet0/0/3]port link-type trunk

[AC1-GigabitEthernet0/0/3]port trunk allow-pass vlan 103

[AC1-GigabitEthernet0/0/3]port trunk pvid vlan 103

[AC1]ip route-static 0.0.0.0 0.0.0.0 10.1.102.2

3. 配置AC给AP分配IP地址，AR给STA分配IP地址

[AC1]dhcp enable

[AC1-Vlanif100]ip add 10.1.100.1 24

[AC1-Vlanif100]dhcp select interface

[AC1-Vlanif101]dhcp select relay

[AC1-Vlanif101]dhcp relay server-ip 10.1.102.2

[AR1]dhcp enable

[AR1-ip-pool-sta]gateway-list 10.1.101.1

[AR1-ip-pool-sta]dns-list 8.8.8.8

[AR1-ip-pool-sta]network 10.1.101.0 mask 24

[AR1-GigabitEthernet0/0/0]ip add 10.1.102.2 24

[AR1-GigabitEthernet0/0/0]dhcp select global

[AR1]ip route-static 10.1.101.0 24 10.23.102.1

4. 配置AP上线

 创建AP组

[AC1]wlan

[AC1-wlan-view]ap-group name ap-group1

 创建域管理模板，在域管理模板下配置AC的国家码并在AP组下引用域管理模板

[AC1-wlan-view]regulatory-domain-profile name domain1

[AC1-wlan-regulate-domain-domain1]country-code cn

[AC1-wlan-view]ap-group name ap-group1

[AC1-wlan-ap-group-ap-group1]regulatory-domain-profile domain1

[AC1]capwap source interface Vlanif 100

 在AC上离线导入AP，并将AP加入AP组

[AC1-wlan-view]ap auth-mode mac-auth

[AC1-wlan-view]ap-id 0 ap-mac 00e0-fc19-7cf0

[AC1-wlan-ap-0]ap-name ap1

[AC1-wlan-ap-0]ap-group ap-group1



5. 配置WLAN业务参数

 创建安全模板，并配置安全策略

[AC1]wlan

[AC1-wlan-view]security-profile name wlan-security

[AC1-wlan-sec-prof-wlan-security]security wapi certificate

[AC1-wlan-sec-prof-wlan-security]wapi asu ip 10.1.103.2

[AC1-wlan-sec-prof-wlan-security]wapi import certificate ac format pem file-name flash:/as.cer

[AC1-wlan-sec-prof-wlan-security]wapi import certificate asu format pem file-name flash:/as.cer

[AC1-wlan-sec-prof-wlan-security]wapi import certificate issuer format pem file-name flash:/as.cer

[AC1-wlan-sec-prof-wlan-security]wapi import private-key format pem file-name flash:/ae.cer

创建SSID模板，并配置SSID名称

[AC1-wlan-view]ssid-profile name wlan-ssid

[AC1-wlan-ssid-prof-wlan-ssid]ssid wlan-net

 创建VAP模板，配置业务数据转发模式、业务VLAN，并且引用安全模板、认证模板和SSID模板

[AC1-wlan-view]vap-profile name wlan-vap

[AC1-wlan-vap-prof-wlan-vap]forward-mode tunnel

[AC1-wlan-vap-prof-wlan-vap]service-vlan vlan-id 101

[AC1-wlan-vap-prof-wlan-vap]security-profile wlan-security

[AC1-wlan-vap-prof-wlan-vap]ssid-profile wlan-ssid

 配置AP组引用VAP模板，AP上射频0和射频1都使用VAP模板的配置

[AC1-wlan-view]ap-group name ap-group1

[AC1-wlan-ap-group-ap-group1]vap-profile wlan-vap wlan 1 radio 0

[AC1-wlan-ap-group-ap-group1]vap-profile wlan-vap wlan 1 radio 1

6. 配置AP射频的信道和功率

 关闭射频的信道和功率自动调优功能

[AC1-wlan-view]rrm-profile name default

[AC1-wlan-rrm-prof-default]calibrate auto-channel-select disable

[AC1-wlan-rrm-prof-default]calibrate auto-txpower-select disable

 配置AP射频的信道和功率

[AC1-wlan-view]ap-id 0

[AC1-wlan-ap-0]radio 0

[AC1-wlan-radio-0/0]channel 20mhz 6

[AC1-wlan-radio-0/0]eirp 127

[AC1-wlan-ap-0]radio 1

[AC1-wlan-radio-0/1]channel 20mhz 149

[AC1-wlan-radio-0/1]eirp 127
