Demining game (analysis)

Catalog

Preface

One 、 Code example and analysis

1、game.h

2、test.c

2、game.c

2.1、 initialization

2.2、 Print chessboard

2.3、 Arrange thunder

2.4、 Check the thunder

2.5、 Expand functions

2.6、 Judge victory

2.7、 Count the number of mines around the target coordinates

Two 、 Demonstration of achievements

1、 Blown up

2、 Spread out a piece of

3、 Mine clearance succeeded

summary

---

Preface

Mine sweeping is my information technology class in senior one , The game we often play when the teacher lets us operate freely , Suddenly I feel so missed .

Use today C Language to achieve mine sweeping game .

Before the official start, sort out what functions are needed for mine sweeping , What steps

General train of thought ：

1、 Print menu

2、 Create array   +   Array initialization

3、 Print chessboard

4、 Arrange thunder

5、 Check the thunder +  6、 Judge victory +  Print chessboard

---

One 、 Code example and analysis

1、game.h

The header file 、define Define constants 、 Function name

Need one 9*9 Array of To store thunder ( The array elements storing thunder cannot be changed ), We also need the same array to store the information of mine screening , But for prevent When checking thunder , Accessing the surrounding coordinates of the target coordinates at the corner position results in An array , So set it to 11*11 Array of , And display Only display the array subscript 1-9 The elements of

The code is as follows （ Example ）：

#pragma once

#include<stdio.h>
#include<stdlib.h>
#include<time.h>

#define ROW 9
#define COL 9

#define ROWS ROW+2
#define COLS COL+2

#define EASY_COUNT 10

void InitBoard(char board[ROWS][COLS], int rows, int cols, char set);
void DisplayBoard(char board[ROWS][COLS], int row, int col);
void SetMine(char mine[ROWS][COLS], int row, int col);
void FindMine(char mine[ROWS][COLS], char show[ROWS][COLS], int row, int col);
int Count_Around_mine(char mine[ROWS][COLS], int x, int y);
void Spread_Show(char mine[ROWS][COLS], char show[ROWS][COLS], int x, int y);
int Iswin(char show[ROWS][COLS], int row, int col);

2、test.c

test.c contain menu,game,main Three functions

The code is as follows （ Example ）：

#define _CRT_SECURE_NO_WARNINGS
#include "game.h"

void menu()
{
	printf("**********************\n");
	printf("******* 1.play *******\n");
	printf("******* 0.exit *******\n");
	printf("**********************\n");
}

// mine Array ：0-- Non thunder   1-- Thunder
void game()
{
	char mine[ROWS][COLS] = { 0 };
	char show[COLS][COLS] = { 0 };
	// initialization
	InitBoard(mine, ROWS, COLS, '0');
	InitBoard(show, ROWS, COLS, '*');
	DisplayBoard(show, ROW, COL);

	// Set ray
	SetMine(mine, ROW, COL);
	//DisplayBoard(mine, ROW, COL);

	// Check the thunder
	FindMine(mine, show, ROW, COL);

}

int main()
{
	srand((unsigned int)time(NULL));
	// Set the starting point for generating random numbers
	int input = 0;

	do
	{
		menu();
		scanf("%d", &input);

		switch (input)
		{
		case 1:
			game();
			break;
		case 0:
			printf(" Game over \n");
			break;
		default:
			printf(" Wrong choice , Please reselect \n");
			break;
		}
	}
	while (input);

	return 0;
}

2、game.c

2.1、 initialization

Pass in a parameter to initialize the content , You can initialize and get different results , That is, the function can be reused

The code is as follows （ Example ）：

// initialization
void InitBoard(char board[ROWS][COLS], int rows, int cols, char set)
{
	int i = 0;
	int j = 0;
	for (i = 0; i < rows; i++)
	{
		for (j = 0; j < cols; j++)
		{
			board[i][j] = set;
		}
	}
}

2.2、 Print chessboard

Attention format

The code is as follows （ Example ）：

// Print chessboard
void DisplayBoard(char board[ROWS][COLS], int row, int col)
{
	printf(" -------- Mine clearance -------\n");
	int i = 0;
	int j = 0;
	for (j = 0; j <= col; j++)
	{
		if (j == 0)
			printf("|");
		if (j < col)
			printf("%d ", j);
		else
			printf("%d|\n", j);
	}
	for (i = 1; i <= row; i++)
	{
		printf("|%d ", i);
		for (j = 1; j <= col; j++)
		{
			if (j < col)
				printf("%c ", board[i][j]);
			else
				printf("%c|\n", board[i][j]);
		}
	}
	printf(" -------- Mine clearance -------\n");

}

2.3、 Arrange thunder

use rand function ,test.c of use srand Function to set the starting point of random number generation

The code is as follows （ Example ）：

// Arrange thunder
void SetMine(char mine[ROWS][COLS], int row, int col)
{
	int count = EASY_COUNT;
	while (count)
	{
		int x = rand() % row + 1;// 1--9
		int y = rand() % col + 1;
		if (mine[x][y] == '0')
		{
			mine[x][y] = '1';
			count--;
		}
	}
}

2.4、 Check the thunder

The check requires multiple input of coordinates , So it's a cycle , Judge after each input 1、 Whether it has been checked ,2、 Is it ray ,3、 Whether there is thunder around , Each cycle Judge whether you win before the end

The code is as follows （ Example ）：

// Check the thunder
void FindMine(char mine[ROWS][COLS], char show[ROWS][COLS], int row, int col)
{
	int x = 0;
	int y = 0;
	while (1)
	{
		printf(" Please enter the coordinates , Such as :1 1\n");
		scanf("%d %d", &x, &y);
		if (x >= 1 && x <= row && y >= 1 && y <= col)
		{
			if (show[x][y] != '*')   // Prevent duplicate input coordinates
			{
				printf(" The coordinates have been checked , Please re-enter other coordinates \n");
			}
			else
			{
				if (mine[x][y] == '0')
				{
					int count = Count_Around_mine(mine, x, y);
					// Expand the function of a piece
					//1. I'm not ray  2. There's no thunder around  3. I haven't been checked
					if (count == 0)
					{
						Spread_Show(mine, show, x, y);
					}
					else
					{
						show[x][y] = count + '0';
					}
					DisplayBoard(show, ROW, COL);
				}
				else
				{
					printf(" unfortunately , You're killed in the blast \n");
					DisplayBoard(mine, ROW, COL);
					break;
				}
			}
		}
		else
		{
			printf(" Illegal coordinates , Please re-enter :>\n");
		}
		if (Iswin(show, ROW, COL) == EASY_COUNT)
		{
			printf(" congratulations , Mine clearance succeeded ！\n");
            break;
		}
	}
}

2.5、 Expand functions

When the input coordinates (x,y) Satisfy ：1、 Not checked ,2、 It's not ray ,3、 There's no thunder around ,x,y The element order at is ' ', You can expand to look around the coordinates 8 A coordinate , Such as x-1,y-1 Also meet the surrounding 8 There is no ray in the coordinates , You can recurse , The condition for setting the stop of recursion is , When x-1,y-1 Around 8 A coordinate When there is thunder x-1,y-1 This position element is the number of surrounding mines

The code is as follows （ Example ）：

// Spread out a piece of ( When there is no thunder in the surrounding coordinates )
void Spread_Show(char mine[ROWS][COLS], char show[ROWS][COLS], int x, int y)
{
	int i = 0;
	int j = 0;
	int count = 0;

	if (x >= 1 && x <= ROW && y >= 1 && y <= COL)  // Prevent the array from going out of bounds when deep recursion
	{
		for (i = -1; i <= 1; i++)   // Judge x,y Whether there is thunder around
		{
			for (j = -1; j <= 1; j++)
			{
				if (mine[x + i][y + j] == '0')
				{
					count = Count_Around_mine(mine, x+i, y+j);
					if (count == 0)
					{
						if (show[x + i][y + j] == '*')// ' ' and '0' Will not enter the cycle , That is, the number has not been checked
						{         // When  i=x,j=y when show[x][y] Has been ordered as '0', Will not enter the cycle
							show[x + i][y + j] = ' ';
							Spread_Show(mine, show, x + i, y + j);
						}
					}
					else if(count>0)// When x,y The surroundings are x+i,y+j When there is thunder around ,x+i,y+j  stay show Numeric characters are given in , End recursion
					{               // exclude count Become negative
						show[x + i][y + j] = count + '0';
					}
				}
			}
		}
	}
}

2.6、 Judge victory

Traverse , If remaining * The number of is equal to the number of Mines set , Just win

The code is as follows （ Example ）：

// Mine clearance victory judgment
Iswin(char show[ROWS][COLS], int row, int col)
{
	int i = 0;
	int j = 0;
	int show_board_mine_count = 0;
	for (i = 1; i <= row; i++)
	{
		for (j = 1; j <= col; j++)
		{
			if (show[i][j] == '*')
				show_board_mine_count++;
		}
	}
	return show_board_mine_count;
}

2.7、 Count the number of mines around the target coordinates

The code is as follows （ Example ）：

// Calculating the surrounding coordinates is the number of Mines
int Count_Around_mine(char mine[ROWS][COLS], int x, int y)
{
	// Law 1
	int i = 0;
	int j = 0;
	int count = 0;
	for (i = -1; i <= 1; i++)
	{
		for (j = -1; j <= 1; j++)
		{
			count += mine[x + i][y + j]-'0';
		}
	}
	return count;
	 Law two
	//return (mine[x - 1][y] +
	//	mine[x - 1][y - 1] +
	//	mine[x][y - 1] +
	//	mine[x + 1][y - 1] +
	//	mine[x + 1][y] +
	//	mine[x + 1][y + 1] +
	//	mine[x][y + 1] +
	//	mine[x - 1][y + 1] - 8 * '0');

}

Two 、 Demonstration of achievements

1、 Blown up

2、 Spread out a piece of

3、 Mine clearance succeeded

---

summary

This article uses C Language to achieve mine clearance , Realized some functions , Due to time , One less Tag function Unrealized , The train of thought is ： stay FindMine Function to create a function that belongs to menu The submenu of , The function can be 1. Check the thunder ,2. Mark ray ,3. Cancel mark ,0. sign out . The idea of modular design is really important , If you can use the function, don't write it in the main function
