The files on disk are files .
But in programming , There are two kinds of documents we usually talk about ： Program files 、 Data files （ Classified from the perspective of file function ）

Program files ：
Include source files （ The suffix is .c）, Target file （windows Environment suffix is .obj）, Executable program （windows Environment suffix is .exe）
Data files ：
The content of the file is not necessarily a program , It's the data that the program reads and writes when it runs , For example, the file from which the program needs to read data , Or output
file name :
A file should have a unique file ID , So that users can identify and reference .
The filename contains 3 part ： File path + File name trunk + file extension
for example ： c:\code\test.txt

The file pointer

Buffer file system , The key concept is “ File type pointer ”, abbreviation “ The file pointer ”.
Each used file has a corresponding file information area in memory , It is used to store information about files （ Such as the name of the document , File status and current file location, etc ）. This information is stored in a structure variable . The structure type is system declared , The name FILE.

for example ,VS2013 The compiler environment provides stdio.h The header file has the following file type declaration ：

Different C Compiler FILE Types don't contain exactly the same content , But it's the same .

Every time you open a file , The system will automatically create a FILE Structural variables , And fill in the information , Users don't have to care about details .

It's usually through a FILE To maintain this FILE Structural variables , This is more convenient to use .

Now we can create a FILE* Pointer variable for : Definition pf It's a point FILE Pointer variable of type data . You can make pf Point to the file information area of a file （ It's a structural variable ）. Through the information in the file information area, you can access the file . in other words , Through the file pointer variable, you can find the file associated with it .

such as ：
struct _iobuf {
char *_ptr;
int _cnt;
char *_base;
int _flag;
int _file;
int _charbuf;
int _bufsiz;
char *_tmpfname;
};
typedef struct _iobuf FILE;

Now we can create a FILE* Pointer variable for :

FILE* pf;// File pointer variable

Definition pf It's a point FILE Pointer variable of type data . You can make pf Point to the file information area of a file （ It's a structural variable ）. Through the information in the file information area, you can access the file . in other words , Through the file pointer variable, you can find the file associated with it .

Opening and closing of files

fopen And fclose

Prototype

fopen

<stdio.h>

FILE * fopen ( const char * filename, const char * mode );

fclose

<stdio.h>

int fclose ( FILE * stream );

If you open it, you close it

Open mode

How files are used meaning                                             If the specified file does not exist
"r"( read-only )    To enter data , Open an existing text file                  error
"w"( Just write ) To output data , Open a text file Create a new file
"a"( Additional ) Add data to the end of the text file Create a new file
"rb"( read-only ) To enter data , Open a binary file                                 error
"wb"( Just write ) To output data , Open a binary file Create a new file
"ab"( Additional ) Add data to the end of a binary file                                            error
"r+"( Reading and writing ) For reading and writing , Open a text file error
"w+"( Reading and writing ) For reading and writing , Suggest a new file Create a new file
"a+"( Reading and writing ) Open a file , Read and write at the end of the file Create a new file
"rb+"( Reading and writing ) Open a binary file for reading and writing                                        error
"wb+"( Reading and writing ) For reading and writing , Create a new binary file Create a new file
"ab+"( Reading and writing ) Open a binary file , Read and write at the end of the file Create a new file

Example

#include<stdio.h>
#include<string.h>
#include<errno.h>
int main()
{
	FILE* pf = fopen("test.txt", "r");// Here it is opened by reading , Because there is no such file under the file, it failed
	if (pf == NULL)		            // If it fails to open, it will return 	NULL
	{
		printf("%s\n",strerror(errno));    // Display error
		return 1;
	}
	// Reading documents
	//……
	// Close file
	fclose(pf);        // Close the file after use
	pf = NULL;         // Set it to null pointer , Prevent random rotation

	return 0;
}

Example ( repair )

Read and write functions

function                                                  Function name                                                              Apply to
Character input function fgetc All input streams
Character output function fputc All output streams
Text line input function fgets All input streams
Text line output function                                 fputs All output streams
Format input function                                 fscanf All input streams
Format output function                                 fprintf All output streams
Binary input                                        fread                                                             file
Binary output                                        fwrite file

fputc

int fputc ( int character, FILE * stream ); // here int Because of the character ASCLL Code value

Writing documents

Example

#include<stdio.h>
#include<string.h>
#include<errno.h>

int main()
{
	FILE* pf = fopen("test.txt", "w");
	if (pf == NULL)		// If it fails to open, it will return 	NULL
	{
		printf("%s\n", strerror(errno));
		return 1;
	}
	// Writing documents
	char i = 0;
	for ( i = 'a'; i < 'z'; i++)
	{
		fputc(i ,pf);
	}

	// Close file 		// Files are also resources , The number of openings is limited , So remember to close the file
	fclose(pf);
	pf = NULL;

	return 0;
}

Reading documents

#include<stdio.h>
#include<string.h>
#include<errno.h>

int main()
{
	FILE* pf = fopen("test.txt", "r");    // Open as read    Data has been written before
	if (pf == NULL)		// If it fails to open, it will return 	NULL
	{
		printf("%s\n", strerror(errno));
		return 1;
	}
	 Writing documents
	//char i = 0;
	//for ( i = 'a'; i < 'z'; i++)
	//{
	//	fputc(i ,pf);
	//}
	 Reading documents
	int ch = fgetc(pf);		// Read once and move backwards
	printf("%c\n", ch);
	ch = fgetc(pf);
	printf("%c\n", ch);
	ch = fgetc(pf);
	printf("%c\n", ch);
	ch = fgetc(pf);
	printf("%c\n", ch);
	ch = fgetc(pf);
	printf("%c\n", ch);

	// Close file 		// Files are also resources , The number of openings is limited , So remember to close the file
	fclose(pf);
	pf = NULL;

	return 0;
}

When reading fails ( Read to the end )

#include<stdio.h>
#include<string.h>
#include<errno.h>

int main()
{
	FILE* pf = fopen("test.txt", "r");
	if (pf == NULL)		// If it fails to open, it will return 	NULL
	{
		printf("%s\n", strerror(errno));
		return 1;
	}
	int ch = 0;
	while ( (ch = fgetc(pf) ) != EOF )
	{
		printf("%c ", ch);
	}
	printf("\n");

	// Close file 		// Files are also resources , The number of openings is limited , So remember to close the file
	fclose(pf);
	pf = NULL;

	return 0;
}

fputs

Prototype

int fputs ( const char * str, FILE * stream );

#include<stdio.h>
#include<string.h>
#include<errno.h>

int main()
{
	FILE* pf = fopen("test.txt", "w");	// write in         // The addition should be changed to 'a'
	if (pf == NULL)		// If it fails to open, it will return 	NULL
	{
		printf("%s\n", strerror(errno));
		return 1;
	}
	 Write a line of data to the file
	fputs("hello world!", pf);


	// Close file 		// Files are also resources , The number of openings is limited , So remember to close the file
	fclose(pf);
	pf = NULL;

	return 0;
}

Be careful ： The clear data here refers to the data in the program that has not been run

fgets

Prototype

char * fgets ( char * str, int num, FILE * stream )

Return value

Read successful ： Return the address where the data is stored
Read failed ： When you read the end of the article or encounter an error when reading NULL

Example

//fgets	// Read a row of data
#include<stdio.h>
#include<string.h>
#include<errno.h>

int main()
{
	FILE* pf = fopen("test.txt", "r");	// write in
	if (pf == NULL)		// If it fails to open, it will return 	NULL
	{
		printf("%s\n", strerror(errno));
		return 1;
	}
	 Read a line of data to the file
	char arr[20] = { 0 };

	fgets(arr, 5, pf);
	printf("%s\n", arr);

	// Close file 		// Files are also resources , The number of openings is limited , So remember to close the file
	fclose(pf);
	pf = NULL;

	return 0;
}

Memory data change

perror

amount to printf("%s\n", strerror(errno));

fprintf

write in

Prototype

int fprintf ( FILE * stream, const char * format, ... );

Example

#include<stdio.h>
struct  S
{
	char arr[10];
	int age;
	float score;
};


int main()
{
	struct S s = { "zhangsan",25,50.5f };
	FILE* pf = fopen("test.txt", "w");
	if (pf == NULL)
	{
		perror("fopen");
		return 1;
	}
	//
	fprintf(pf, "%s %d %f", s.arr, s.age, s.score);

	fclose(pf);
	pf = NULL;
	return 0;
}

fscanf

Reading data

Prototype

int fscanf ( FILE * stream, const char * format, ... );

Example

#include<stdio.h>
struct  S
{
	char arr[10];
	int age;
	float score;
};

int main()
{
	struct S s = { 0 };
	FILE* pf = fopen("test.txt", "r");    // Here is the data reading , Read from file
	if (pf == NULL)                       // The data has been written before
	{
		perror("fopen");
		return 1;
	}
	fscanf(pf, "%s %d %f", s.arr, &s.age, &s.score);
	printf("%s %d %f\n", s.arr, s.age, s.score);

	fclose(pf);
	pf = NULL;
	return 0;
}

Simply understand the flow

flow
//FILE*

//printf
//scanf

Any one of them C Program , As long as it runs, it will clock in by default 3 A flow
FILE* stdin - Standard input stream ( keyboard )
FILE* stdout - Standard output stream ( The screen )
FILE* stderr - Standard error flow ( The screen )

Here, the data can also be directly printed out by using the standard output stream

fwrite

Output in binary -- Write

Prototype

size_t fwrite ( const void * ptr, size_t size, size_t count, FILE * stream );
Four parameters
1. Address , Address of the data to be written
2. size , The size of such data
3. Number , How many such data are written
4. The pointer , The file pointer

#include<stdio.h>
struct  S
{
	char arr[10];
	int age;
	float score;
};

int main()
{
	struct S s = { "zhangsan",25,50.5f };
	FILE* pf = fopen("test.txt", "wb");
	if (pf == NULL)
	{
		perror("fopen");
		return 1;
	}
	// Write... In binary
	fwrite(&s, sizeof(struct S), 1, pf);

	fclose(pf);
	pf = NULL;
	return 0;
}

there zhangsan It can be seen that the binary mode is the same as the text mode , So we can understand
We can do it in VS Put this inside txt Add to it , Right click open mode to open in binary mode , You can see the appearance of its binary file . Of course, writing in binary mode naturally requires reading in binary mode , The following demonstration

fread

size_t fread ( void * ptr, size_t size, size_t count, FILE * stream );

Return value ： Return the actual number of reads

#include<stdio.h>
struct  S
{
	char arr[10];
	int age;
	float score;
};

int main()
{
	struct S s = { 0 };
	FILE* pf = fopen("test.txt", "rb");
	if (pf == NULL)
	{
		perror("fopen");
		return 1;
	}
	// Read in binary
	fread(&s, sizeof(struct S), 1, pf);
	printf("%s %d %f\n", s.arr, s.age, s.score);

	fclose(pf);
	pf = NULL;
	return 0;
}

So we can understand

sscanf And sprintf

These two are not functions of file operation

Prototype

sprintf
int sprintf ( char * str, const char * format, ... );
sscanf
int sscanf ( const char * s, const char * format, ...);

Example

#include<stdio.h>
struct  S
{
	char arr[10];
	int age;
	float score;
};


int main()
{
	struct S s = { "zhangsan",25,50.5f };
	char buf[100] = {0};
	struct S tmp = { 0 };
	//sprintf
	// hold  s  The formatted data in is converted into a string and placed in buf in
	sprintf(buf, "%s %d %f", s.arr, s.age, s.score);
	printf(" character string ：%s\n", buf);

	//sscanf
	// From a string  buf  Get a formatted data to tmp in
	sscanf(buf, "%s %d %f", tmp.arr, &tmp.age, &tmp.score);
	printf(" format ：%s %d %f\n",tmp.arr,tmp.age,tmp.score);

	return 0;
}

Random, speaking, reading and writing

Locate the file pointer according to its position and offset

fseek

Prototype

int fseek ( FILE * stream, long int offset, int origin );

Three positioning symbols

SEEK_SET -- Read from file
SEEK_CUR -- Offset backward from the read position
SEEK_END -- Read from the end of the file

#include<stdio.h>
#include<errno.h>
#include<string.h>

int main()
{
	FILE* pf = fopen("test.txt", "r");
	if (pf == NULL)
	{
		printf("%s\n", strerror(errno));
		return 1;
	}
	// Reading documents
	// Locate file pointer
	//SEEK_SET
	fseek(pf, 2, SEEK_SET);
	int ch = fgetc(pf);
	printf("%c\n", ch);

	//SEEK_CUR
	fseek(pf, 2, SEEK_CUR);
	ch = fgetc(pf);
	printf("%c\n", ch);

	//SEEK_END
	fseek(pf, -1, SEEK_END);
	ch = fgetc(pf);
	printf("%c\n", ch);

	return 0;
}

ftell

Calculate the current offset

Prototype

long int ftell ( FILE * stream );

#include<stdio.h>
#include<errno.h>
#include<string.h>

int main()
{
	FILE* pf = fopen("test.txt", "r");
	if (pf == NULL)
	{
		printf("%s\n", strerror(errno));
		return 1;
	}
	// Reading documents
	// Locate file pointer
	//SEEK_SET
	fseek(pf, 2, SEEK_SET);
	int ch = fgetc(pf);
	printf("%c\n", ch);
	printf("%d\n", ftell(pf));

	//SEEK_CUR
	fseek(pf, 2, SEEK_CUR);
	ch = fgetc(pf);
	printf("%c\n", ch);
	printf("%d\n", ftell(pf));

	//SEEK_END
	fseek(pf, -1, SEEK_END);
	ch = fgetc(pf);
	printf("%c\n", ch);
	printf("%d\n", ftell(pf));

	return 0;
}

rewind

Return the file pointer to the beginning of the file

void rewind ( FILE * stream );

#include<stdio.h>
#include<errno.h>
#include<string.h>

int main()
{
	FILE* pf = fopen("test.txt", "r");
	if (pf == NULL)
	{
		printf("%s\n", strerror(errno));
		return 1;
	}
	// Reading documents
	// Locate file pointer
	//SEEK_SET
	fseek(pf, 2, SEEK_SET);
	int ch = fgetc(pf);
	printf("%c\n", ch);
	printf("%d\n", ftell(pf));

	//SEEK_CUR
	fseek(pf, 2, SEEK_CUR);
	ch = fgetc(pf);
	printf("%c\n", ch);
	printf("%d\n", ftell(pf));

	//SEEK_END
	fseek(pf, -1, SEEK_END);
	ch = fgetc(pf);
	printf("%c\n", ch);
	printf("%d\n", ftell(pf));

	//rewind
	rewind(pf);
	ch = fgetc(pf);
	printf("%c\n", ch);
	printf("%d\n", ftell(pf));

	fclose(pf);
	pf = NULL;

	return 0;
}

Text files and binaries

According to the organization of data , Data files are called text file perhaps Binary .
Data is stored in memory in binary form , If the output without conversion is to external memory , Namely Binary .
If it's required to use ASCII In the form of code , You need to convert before storing . With ASCII The file stored in the form of characters is text file .
A data in memory
All characters are written in ASCII stored , Numerical data can be used either ASCII stored , It can also be stored in binary form . If there are integers 10000, If the ASCII Code output to disk , The disk is occupied by 5 Bytes （ One byte per character ）, And binary output , On the disk 4 Bytes （VS2013 test ）

#include <stdio.h>
int main()
{
	int a = 10000;
	FILE* pf = fopen("test.txt", "wb");
	fwrite(&a, 4, 1, pf);// The binary form is written to the file
	fclose(pf);
	pf = NULL;
	return 0;
}

Determination of the end of file reading

Misused feof

Keep in mind ： During file reading , Out-of-service feof The return value of the function is directly used to determine whether the end of the file .
It is Apply when the file reading is finished , The judgment is that the read failed and ended , Or end of file .
1. Whether the reading of text file is finished , Determine whether the return value is EOF （ fgetc ）, perhaps NULL （ fgets ）
for example ：
fgetc Judge whether it is EOF .
fgets Determine whether the return value is NULL .
2. Judgment of reading end of binary file , Judge whether the return value is less than the actual number to be read .
for example ：
fread Judge whether the return value is less than the actual number to be read .

feof

Prototype

int feof ( FILE * stream );

Examples of text files ：

#include <stdio.h>
#include <stdlib.h>
int main(void) {
    int c; //  Be careful ：int, Not char, Ask to deal with EOF
    FILE* fp = fopen("test.txt", "r");
    if(!fp) {
        perror("File opening failed");
        return EXIT_FAILURE;
   }
 //fgetc  When reading fails or the end of the file is encountered , Will return to EOF
    while ((c = fgetc(fp)) != EOF) //  standard C I/O Read file cycle
   {
       putchar(c);
   }
 // Judge why it ended
    if (ferror(fp))    // Determine whether to encounter I/O error
        puts("I/O error when reading");
    else if (feof(fp))
        puts("End of file reached successfully");
    fclose(fp);
}

Examples of binary files ：

#include <stdio.h>
enum { SIZE = 5 };
int main(void) {
    double a[SIZE] = {1.,2.,3.,4.,5.};
    FILE *fp = fopen("test.bin", "wb"); //  Binary mode must be used
    fwrite(a, sizeof *a, SIZE, fp); //  Write  double  Array of
    fclose(fp);
    double b[SIZE];
    fp = fopen("test.bin","rb");
    size_t ret_code = fread(b, sizeof *b, SIZE, fp); //  read  double  Array of
    if(ret_code == SIZE) {
        puts("Array read successfully, contents: ");
        for(int n = 0; n < SIZE; ++n)
        printf("%f ", b[n]);
        putchar('\n');
   } else { // error handling
       if (feof(fp))   // Judge whether to read to the end
          printf("Error reading test.bin: unexpected end of file\n");
       else if (ferror(fp)) // Determine whether there is a reading error
       {
           perror("Error reading test.bin");
       }
   }
    fclose(fp);
}

File buffer

ANSIC The standard is “ Buffer file system ” Processing of data files , The so-called buffer file system means that the system automatically opens up a block in memory for each file being used in the program “ File buffer ”. Data output from memory to disk is first sent to a buffer in memory , After the buffer is filled, it is sent to the disk together . If you read data from disk to computer , Then read the data from the disk file and input it into the memory buffer （ Fill the buffer ）, And then send the data from the buffer to the program data area one by one （ Program variables, etc ）. The size of the buffer depends on C The compiler system decides .

Example

VS2013 WIN10 Environmental testing

#include <stdio.h>
#include <windows.h>
//VS2013 WIN10 Environmental testing
int main()
{
 FILE*pf = fopen("test.txt", "w");
 fputs("abcdef", pf);// Put the code in the output buffer first
 printf(" sleep 10 second - The data has been written , open test.txt file , Found no content in the file \n");
 Sleep(10000);
 printf(" Refresh buffer \n");
 fflush(pf);// When the buffer is flushed , Write the data in the output buffer to a file （ disk ）
 // notes ：fflush  In high version VS It can't be used on
 printf(" Sleep again 10 second - here , Open again test.txt file , There's something in the file \n");
 Sleep(10000);
 fclose(pf);
 // notes ：fclose When closing a file , It also flushes the buffer
 pf = NULL;
 return 0;
}

Run the code and you can see the changes of the data in the file , It passes through the buffer
Here we can get a Conclusion ：
Because there is a buffer ,C Language when operating files , You need to flush the buffer or close the file at the end of the file operation .
If you don't do , May cause problems in reading and writing files .
