Yingjixin launched 4 series of lithium batteries 100W mobile power supply voltage rise and fall scheme SOC chip ip5389

CIMC recently launched a product suitable for ,4 Lithium battery series charging 100W Mobile power supply voltage rise and fall scheme SoC chip IP5389.

summary ：

Yingjixin IP5389 It's an integrated QC2.0 / QC3.0 / QC3+ Output fast charging protocol ,AFC/FCP/ SCP/ VOOC I / O fast charging protocol 、USB C PD2.0/PD3.0 I / O protocol 、USB C PD3.0 PPS Output protocol 、 compatible BC1.2/ Apple mobile phone 、 Synchronous bidirectional voltage rise and fall converter 、 Lithium battery charging management 、 Multifunctional power management such as battery power indication SOC, Provide complete power solution for fast charging mobile power supply . Can support at the same time USB A x2, USB C, USB B（ or lightning mouth , or USBC） four USB mouth , Use either alone USB Both ports can support fast charging , When two or more outlets are used at the same time , Only support 5V.

   IP5389 Support 2/3/4/5 Section series cell , The synchronous switch voltage raising and lowering system can provide maximum 100W Output capability . When empty , Automatically enter sleep state .

  IP5389 built-in 14bit ADC, Accurately measure battery voltage and current .IP5389 Built in power calculation method , Accurate battery power information can be obtained . Customizable battery power curve , To accurately display the battery level .

  IP5389 Support 4 star LED Electricity display , Support 88、188 And other digital tube power display ; Support lighting function ; Support key .

characteristic ：

（ One ） Support multiple USB  mouth

（1）2 individual USB A output

（2）1 individual USB C I want to input / Output

（3）1 individual USB B Mouth or  Lightning Port input or C I want to input / Output

（ Two ） Fast charging specifications

（1） Any port supports fast charging

（2） Integrate QC2.0/QC3.0/QC3+ Output fast charging protocol

（3） Integrate FCP Input / Output fast charging protocol

（4） Integrate AFC Input / Output fast charging protocol

（5） Integrate SCP Input / Output fast charging protocol

（6） Integrate VOOC Input / Output fast charging protocol

（7） Integrate DRP try.SRC agreement ,PD3.0 Input / Output fast charge

（8） compatible BC1.2、 Apple mobile phone fast charging
