SQL master-slave replication setup

Catalog

mysql Master-slave introduction

Master slave building

Operate on the host database

---



mysql Master-slave introduction

mysql To copy from a computer ：

slave From master Read binlog To synchronize data

1 master The host logs the changes to the binary log （binary log）. These recording processes are called Binary log events ,binary log events;
2 slave take master Of binary log events Copy to its trunk log （relay log）;
3 slave Redo events in relay log , Apply the changes to your own database . MySQL Replication is asynchronous and serialized

Several processing modes ：

statement Pattern ： You can't use functions , For example, your host uses functions now() Record the time, but when synchronizing to the slave , His time will change （ Obviously inconsistent ）, This will cause the master-slave replication data to be sent in case of inconsistency （ I feel a bit like RDB, Direct data synchronization , There will be data inconsistencies ）;

Row mode row： Low efficiency , Record the changes in each line , If the data volume reaches a level, it will be very slow （ I feel a bit like AOF, Give each line of the slave to execute ）;

MIXED Pattern ： A combined version of the previous two modes ;

Master slave building

Modify the configuration file of the host ：

Find the host first mysql Configuration file for my.ini, Then configure Log files Directory and settings of Databases that don't need to be replicated and The name of the database to be copied



Then modify the configuration file of the slave ：

  Yes my.cnf File modification

1. Create a user in the host , Have all permissions in the native database

# On host local , Give the remote permission
GRANT REPLICATION SLAVE ON *.* TO 'slave190401'@'%' IDENTIFIED BY '123';



  View the host database status

show master status



2. restart mysql host

 3. And then in linux Next restart our mysql Slave

systemctl restart mysqld

4. Then let's look at mysql Of status, Find out running active that will do

systemctl status mysqld

5. And then in window Close all firewalls

And close linux Under the firewall stop

systemctl status firewalld

mysql Master slave copy and redis Those are a bit similar

Accessing the host from the host Binary log All need to be verified , See if you can visit , And ours redis The cluster accesses the host from the host （ That is, to get the host RDB、AOF file ）, You also need to verify whether the data is loaded for the first time , And this verification is to see id Is it the same

Binlog_Do_DB and Binlog_Ignore_DB It refers to the database to be copied and the database not to be copied

At this time, the host computer should not be responsible for this Bin_Do_DB Database operation , This is the master-slave database , If it changes ,Position Will send changes

6. At this point, we need to deal with linux Under the mysql To operate ： Thanks to the host , Follow slave of It's kind of like

CHANGE MASTER TO MASTER_HOST='192.168.184.1',
MASTER_USER='slave190401',
MASTER_PASSWORD='123',
MASTER_LOG_FILE='mysqlbin.000001',MASTER_LOG_POS=107;

7. If there is a problem from the slave to the host , need reset once

stop slave

reset master

  Then we start master-slave replication

start slave

8. Check the slave status （ similar redis Medium info replication）

show slave status\G

Operate on the host database

Operate on the host to create mydb_190401 After the database , It is found that the database to which the slave user is connected also has

There is a delay , millisecond , perfect bro

  If there is a mistake in your order to worship brother from the machine , direct stop slave Stop slave , then reset master that will do ——> Go back to the executive brother Before the command
