Huawei AP-3010DN_V2 Configuration creation wifi

First, plug the network cable from Guangmao into Huawei wireless access point PoE On the mouth , Because Huawei AP Default management IP yes 169.254.1.1, So use it wifi On the computer with wireless Internet , Modify NIC IP by 169.254.1.2, Then the browser accesses 169.254.1.1, The default username password is admin and [email protected], Change the password for the first time ,（ Long press default Jack 3 Seconds can clear the password and restore factory ）, And then put vlanif1 Of ip Change it to `192.168.1.2`（ If and others vlan Conflict first delete other vlan）, After saving, you can put the computer ip Change back to the original Internet IP 了 , Then use `192.168.1.2` Visit Huawei wireless management again web Carry out subsequent configuration at the end wifi The operation of .

The previous part can be referred to

Old tube weblog | funpower's blog » Blog Archive » Huawei Wireless AP——AP3010DN-V2 Configuration example （ Configure as fat mode home ordinary router mode ）http://guanjianfeng.com/archives/1160231 It's just that you don't have to connect your computer directly to Huawei equipment ,【PC・・wifi・・ Naked cat —— equipment 】 It's fine too .

Later on Reprinted in Zhihu Huawei AP-3010DN_V2 Configuration instructions - You know , author People climb on the grass-roots level

To configure

newly build VLAN

Set up VLAN

Build another one VLAN

Set up VLAN

The result after setting

Set the Ethernet interface according to the figure

newly build DHCP

Set up DHCP

newly build NAT mapping

Set up NAT

Set as shown DNS

The wizard

newly build WI-FI Signal setting

Fill in the basic information

Address and rate configuration

next step

complete

Here we are ,AP Setup completed .
