(original) customize a scrolling recyclerview

Effect display

RecyclerView You can customize it into various styles you want
For example, the home page Banner, Card style, etc
Today, let's share a rolling RecyclerView, Let's see the effect first ：

Here is how to realize

Adapter

First of all adapter, Because to achieve infinite scrolling , So in getItemCount Method returns Integer.MAX_VALUE
The specific code is as follows ：

public class AutoPollAdapter extends RecyclerView.Adapter {


    /** *  Event callback monitoring  */

    private OnItemClickListener onItemClickListener;

    private Context context;

    private List<AutoBean> listBeans;

    public AutoPollAdapter(Context context, List<AutoBean> listBeans) {

        this.context = context;
        this.listBeans = listBeans;
    }

    @Override
    public ViewHolder onCreateViewHolder(ViewGroup parent, int viewType) {

        //  Instantiate the view
        View view = LayoutInflater.from(parent.getContext()).inflate(R.layout.item_auto_poll, parent, false);

        //  Instantiation viewholder
        ViewHolder viewHolder = new ViewHolder(view);
        viewHolder.imgHead = view.findViewById(R.id.img_head);
        viewHolder.tvName = view.findViewById(R.id.tv_name);
        return viewHolder;
    }



    @Override
    public void onBindViewHolder(@NonNull RecyclerView.ViewHolder holder, int position) {

        ViewHolder holder1 = (ViewHolder) holder;
        holder1.tvName.setText(listBeans.get(position % listBeans.size()).tvname);
        Glide.with(context).load(listBeans.get(position % listBeans.size()).url).into(holder1.imgHead);
        holder1.tvName.setOnClickListener(new View.OnClickListener() {

            @Override
            public void onClick(View v) {

                onItemClickListener.onItemClick((position % listBeans.size()));
                }
        });
    }


    @Override
    public int getItemCount() {

        // Mainly here , Achieve the effect of wireless rotation
        return Integer.MAX_VALUE;
    }

    public static class ViewHolder extends RecyclerView.ViewHolder {

        TextView tvName;
        ImageView imgHead;

        public ViewHolder(View itemView) {

            super(itemView);
        }
    }

    /** *  Set callback monitor  * * @param listener */

    public void setOnItemClickListener(OnItemClickListener listener) {


        this.onItemClickListener = listener;

    }

    public interface OnItemClickListener {


        void onItemClick(int position);

    }

}

dependent xml also bean Also put on ：

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android" android:layout_width="match_parent" android:orientation="horizontal" android:gravity="center_vertical" android:layout_height="60dp">

    <ImageView android:id="@+id/img_head" android:layout_width="56dp" android:layout_height="56dp" android:src="@drawable/ic_launcher" />

    <TextView android:id="@+id/tv_name" android:text=" test " android:layout_marginLeft="10dp" android:layout_width="match_parent" android:layout_height="wrap_content" />


</LinearLayout>

public class AutoBean {

    String tvname;
    String url;

    public AutoBean(String tvname, String url) {

        this.tvname = tvname;
        this.url = url;
    }

}

Self defined LinearLayoutManager

Customize a layoutManager, To control the sliding speed ：

public class ScrollSpeedLinearLayoutManger extends LinearLayoutManager {


    private float MILLISECONDS_PER_INCH = 0.03f;

    private Context contxt;


    public ScrollSpeedLinearLayoutManger(Context context) {


        super(context);

        this.contxt = context;
    }

    @Override
    public void smoothScrollToPosition(RecyclerView recyclerView, RecyclerView.State state, int position) {


        LinearSmoothScroller linearSmoothScroller =
                new LinearSmoothScroller(recyclerView.getContext()) {

                    @Override
                    public PointF computeScrollVectorForPosition(int targetPosition) {

                        return ScrollSpeedLinearLayoutManger.this
                                .computeScrollVectorForPosition(targetPosition);
                    }

                    @Override
                    protected float calculateSpeedPerPixel

                            (DisplayMetrics displayMetrics) {


                        setSpeedSlow();

                        return MILLISECONDS_PER_INCH / displayMetrics.density;
// return 7;
                        //  Slide back one pixel How many milliseconds does it take
                    }
                };

        linearSmoothScroller.setTargetPosition(position);

        startSmoothScroll(linearSmoothScroller);

    }

    public void setSpeedSlow() {


        // Use it here by yourself density Go by , I hope the sliding speed is the same on devices with different resolutions

        //0.3f It is a value estimated by oneself , It can be modified according to different needs

        MILLISECONDS_PER_INCH = contxt.getResources().getDisplayMetrics().density * 3f;

    }

    public void setSpeedFast() {


        MILLISECONDS_PER_INCH = contxt.getResources().getDisplayMetrics().density * 0.03f;

    }

}

Self defined RecyclerView

And then put your own RecyclerView：

public class AutoPollRecyclerView extends RecyclerView {


    private static final long TIME_AUTO_POLL_1 = 2000;

    AutoPollTask autoPollTask;

    private int index = 2;// This value is very important , Slide the animation to the first few

    private boolean running; // Indicates whether automatic polling is in progress

    private boolean canRun;// Indicates whether automatic polling is possible , It can be set when it is not needed false

    public AutoPollRecyclerView(Context context, @Nullable AttributeSet attrs) {


        super(context, attrs);

        autoPollTask = new AutoPollTask(this);
    }


    /*** *  You can only slide one at a time item（ Shuffling figure ） */

    static class AutoPollTask implements Runnable {


        private final WeakReference<AutoPollRecyclerView> mReference;

        // Use weak references to hold external class references -> Prevent memory leaks

        public AutoPollTask(AutoPollRecyclerView reference) {


            this.mReference = new WeakReference<AutoPollRecyclerView>(reference);

        }

        @Override
        public void run() {


            AutoPollRecyclerView recyclerView = mReference.get();

            if (recyclerView != null && recyclerView.running && recyclerView.canRun) {


                recyclerView.smoothScrollToPosition(++recyclerView.index);

                recyclerView.postDelayed(recyclerView.autoPollTask, TIME_AUTO_POLL_1);

            }

        }

    }

    // Turn on : If it's running , First stop -> And open
    public void start() {

        if (running)
            stop();
        canRun = true;
        running = true;
        postDelayed(autoPollTask, TIME_AUTO_POLL_1);

    }

    public void stop() {


        running = false;

        removeCallbacks(autoPollTask);

    }



    //  Achieve a gradient effect
    Paint mPaint;

    private int layerId;

    private LinearGradient linearGradient;

    /** *  No sliding  * @param e * @return */
    public boolean onTouchEvent(MotionEvent e) {

        return true;
    }
    /** *  No sliding  * @param e * @return */
    @Override
    public boolean onInterceptTouchEvent(MotionEvent e) {

        return false;
    }

    private int preWidth = 0;// Recyclerview When the width changes dynamically , Monitor the width of each time

    public void doTopGradualEffect(final int itemViewWidth) {


        mPaint = new Paint();

        // dst_in  Pattern , Realize that the bottom transparency is displayed synchronously with the top transparency （ That is, when the upper layer is transparent , The lower layer is transparent , It's not that the upper layer covers the lower layer )

        final Xfermode xfermode = new PorterDuffXfermode(PorterDuff.Mode.DST_IN);

        mPaint.setXfermode(xfermode);

        addItemDecoration(new RecyclerView.ItemDecoration() {


            @Override

            public void onDrawOver(Canvas canvas, RecyclerView parent, RecyclerView.State state) {

                super.onDrawOver(canvas, parent, state);
                //  When linearGradient If it is empty, it means that it is drawn for the first time   or  Recyclerview When the width changes , Recalculate the transparent position
                if (linearGradient == null || preWidth != parent.getWidth()) {

                    //  Transparent position from the last  itemView  Half way to  Recyclerview  On the far right of
                    linearGradient = new LinearGradient(parent.getWidth() - (itemViewWidth / 2), 0.0f, parent.getWidth(), 0.0f, new int[]{
    Color.BLACK, 0}, null, Shader.TileMode.CLAMP);
                    preWidth = parent.getWidth();
                }

                mPaint.setXfermode(xfermode);

                mPaint.setShader(linearGradient);

                canvas.drawRect(0.0f, 0.0f, parent.getRight(), parent.getBottom(), mPaint);

                mPaint.setXfermode(null);
                canvas.restoreToCount(layerId);

            }

            @Override

            public void onDraw(Canvas c, RecyclerView parent, RecyclerView.State state) {


                super.onDraw(c, parent, state);
                //  here  Paint Parameters of are passed here null,  In the incoming  mPaint  There will be the problem of flashing black screen for the first time
                //  Be careful  saveLayer  Cannot save nor move to onDrawOver In the method
                layerId = c.saveLayer(0.0f, 0.0f, (float) parent.getWidth(), (float) parent.getHeight(), null, Canvas.ALL_SAVE_FLAG);
            }

            @Override

            public void getItemOffsets(Rect outRect, View view, RecyclerView parent, RecyclerView.State state) {

                super.getItemOffsets(outRect, view, parent, state);

            }

        });

    }

}

One thing to note here , Because our scrolling , I don't want him to slide through his fingers
That is to say, disable RecyclerView Your fingers slide
The general solution is to rewrite layoutManager Two approaches ：
canScrollVertically and canScrollHorizontally
return false, Disable left and right sliding and up and down sliding respectively
But this will bring a new problem ：
RecyclerVIew Use this method to prevent sliding , adopt smoothScrollToPosition Slide to specified item Our methods have also failed
In this way, the automatic scrolling effect is gone
I didn't use this method , It uses rewriting RecyclerView The next two methods of ：

    /** *  No sliding  * @param e * @return */
    public boolean onTouchEvent(MotionEvent e) {

        return true;
    }
    /** *  No sliding  * @param e * @return */
    @Override
    public boolean onInterceptTouchEvent(MotionEvent e) {

        return false;
    }

So if you want to open the finger slide , Comment on these two methods , Then record the position where the monitor slides , Reset auto slide （ That's important ）
You can realize this by yourself

Use

Last , Paste the code used ：

<?xml version="1.0" encoding="utf-8"?>
<FrameLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context=".MainActivity">

    <com.example.mydemo.recy.AutoPollRecyclerView
        android:id="@+id/recycleView"
        android:fadingEdge="vertical"
        android:scrollbars="none"
        android:fadingEdgeLength="10dp"
        android:layout_width="match_parent"
        tools:listitem="@layout/item_auto_poll"
        android:layout_height="180dp"/>


</FrameLayout>

public class MainActivity extends AppCompatActivity {


    @Override
    protected void onCreate(Bundle savedInstanceState) {

        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main_recy);
        ScrollSpeedLinearLayoutManger layoutManager = new ScrollSpeedLinearLayoutManger(this);

        layoutManager.setSmoothScrollbarEnabled(true);

        layoutManager.setAutoMeasureEnabled(true);
        AutoPollRecyclerView recyclerView = findViewById(R.id.recycleView);

        recyclerView.setLayoutManager(layoutManager);//  Layout manager .
        recyclerView.setHasFixedSize(true);//  If Item Simple enough , The height is certain , open FixSize Will improve performance .
        recyclerView.setItemAnimator(new DefaultItemAnimator());//  Set up Item Default animation , Plus is OK , It's ok if you don't add it .
        ArrayList<AutoBean> list = new ArrayList<>();
        list.add(new AutoBean(" Doraemon A dream ","https://gimg2.baidu.com/image_search/src=http%3A%2F%2Fup.enterdesk.com%2Fedpic_source%2F91%2F81%2Fd7%2F9181d7d8787f7e96f0017da5e61ad27d.jpg&refer=http%3A%2F%2Fup.enterdesk.com&app=2002&size=f9999,10000&q=a80&n=0&g=0n&fmt=auto?sec=1659497299&t=05f317ff452b3f1a452f7e06c9ce8703"));
        list.add(new AutoBean(" puppy ","https://gimg2.baidu.com/image_search/src=http%3A%2F%2Fc-ssl.duitang.com%2Fuploads%2Fitem%2F201610%2F17%2F20161017213843_EeViB.thumb.1000_0.jpeg&refer=http%3A%2F%2Fc-ssl.duitang.com&app=2002&size=f9999,10000&q=a80&n=0&g=0n&fmt=auto?sec=1659497393&t=6f8f90c5b409231ef5902aafc7464d31"));
        list.add(new AutoBean(" Cartoon head ","https://gimg2.baidu.com/image_search/src=http%3A%2F%2Fc-ssl.duitang.com%2Fuploads%2Fblog%2F202107%2F09%2F20210709142454_dc8dc.thumb.1000_0.jpeg&refer=http%3A%2F%2Fc-ssl.duitang.com&app=2002&size=f9999,10000&q=a80&n=0&g=0n&fmt=auto?sec=1659497417&t=1a38f19555bcb59f5f9e127126fba84a"));
        list.add(new AutoBean(" Fire shadow avatar ","https://gimg2.baidu.com/image_search/src=http%3A%2F%2Finews.gtimg.com%2Fnewsapp_bt%2F0%2F13207652291%2F1000.jpg&refer=http%3A%2F%2Finews.gtimg.com&app=2002&size=f9999,10000&q=a80&n=0&g=0n&fmt=auto?sec=1659497813&t=a911ff64c37a57aeb95a6f31d13a573b"));
        AutoPollAdapter autoPollAdapter = new AutoPollAdapter(MainActivity.this, list);
        autoPollAdapter.setOnItemClickListener(new AutoPollAdapter.OnItemClickListener() {

            @Override
            public void onItemClick(int position) {

                Log.d("AutoPollAdapter", " Click. " + (position));
                Toast.makeText(MainActivity.this, " Click. " + (position ), Toast.LENGTH_SHORT).show();
            }
        });
        recyclerView.setAdapter(autoPollAdapter);

        recyclerView.start();
        DisplayMetrics dm = getResources().getDisplayMetrics();
        recyclerView.doTopGradualEffect(dm.widthPixels);

    }
}

Last but not least ：
If you want to recycleview It shows item The quantity is an integer
For example, three ,
that recycleview Height , Be sure to set it to item An integral multiple of the height of
For example, three times , It means you can display three item, Five times shows five .
