Shooting lesson 1-01: Introduction

Shooting The first 1-1 course ： introduction

pygame

This is our tutorial series “ Use Pygame Develop games ” Of the 1 part . It is suitable for game development and improvement Python Beginners interested in coding skills / Intermediate programmer .

What is? Pygame？

Pygame It's a “ Game library ” - A set of tools to help programmers make games . Some of them are ：

• Graphics and animation
• voice （ Including music ）
• control （ keyboard 、 mouse 、 Game controller, etc ）

Game cycle

The core of every game is a cycle , We call it “ Game cycle ”. This cycle keeps running , Over and over again , Do all the things that make the game work . Every time the game goes through this cycle , Called frame .

Every frame , A lot of different things can happen , But they can be organized into three different categories ：

1. Process input （ Or event ）

Anything the game needs to respond to . These may be keyboard keys , Mouse movement, etc .

2. Update game

Change anything that needs to be changed on the framework . If a character is in the air , Gravity needs to pull it down . If two objects collide with each other , They need to explode .

3. Rendering （ Or draw ）

In this step , We will draw everything on the screen . background 、 role 、 Menus or any other content that players need to view must be drawn in the correct position on the screen .

The clock

Another important aspect of the cycle is to control the running speed of the whole cycle . You may have heard of the term FPS, It represents frames per second . This means how many times per second this cycle should occur . It's important , Because you don't want the game to run too fast or too slow . You don't want it to run at different speeds on different computers .

structure Pygame Templates

Now we know what it takes to make the game work , We can start writing some code . First , We will make a simple pygame Program , In addition to opening a window and running the game loop , Don't do anything? . For anything you want to make pygame For projects , This will be a good starting point .

At the top of the program , We will import the required libraries , And set some variables for game options ：

# Pygame  Templates  -  Game framework
import pygame
import random

WIDTH = 360  #  Game window width
HEIGHT = 480 #  Game window height
FPS = 30 #  Frames per second

Next we need to open the game window ：

#  initialization pygame, create a window
pygame.init()
pygame.mixer.init()  # for sound
screen = pygame.display.set_mode((WIDTH, HEIGHT))
pygame.display.set_caption("My Game")
clock = pygame.time.Clock()

pygame.init() It's startup pygame and “ initialization ”. Will create a game screen . Last , We have created a system that can ensure that the game is what we want FPS Running screen clock

Next is the game cycle ：

#  Game cycle
running = True
while running:
    # Process input (events)
    # Update
    # Render (draw)

This is our game cycle , It is a loop controlled by variables . If we want the game to end , Just set up running = False It will end the cycle . Now we can fill each part with some basic code .``

Rendering / The drawing part

We will start from *“ draw *” Part of it . We don't have any code yet , But we can fill the screen with solid colors . So , We need to discuss how computers deal with colors .

The computer screen is made up of pixels , These pixels have 3 Parts of ： Red 、 Green and blue . The degree to which each part is lit determines the color of the pixel , As shown below ：

Each of the three primary colors can have a color between 0（ close ） and 255（100% open ） Between the value of the , Therefore, each of the three primary colors has 256 There are two different possibilities . Here are some examples of some colors you can make ：

You can find the total number of colors that the computer can display by multiplication ：

    >>> 256 * 256 * 256 = 16,777,216

Now we have learned about color , Let's define some at the top of the program ：

# Colors (R, G, B)
BLACK = (0, 0, 0)
WHITE = (255, 255, 255)
RED = (255, 0, 0)
GREEN = (0, 255, 0)
BLUE = (0, 0, 255)

Then we can fill the screen with black .

    #  draw 、 Rendering
    screen.fill(BLACK)

For the working mode of computer display , It is not enough . Changing the pixels on the screen means having the graphics card tell the monitor to change the actual pixels . In terms of computers , It's a very, very slow process . therefore , If you want to draw a lot of things on the screen , It may take a long time to draw them all . We can call it Double buffering Something that solves this problem in a smart way . It sounds fancy , But it actually just means ：

Imagine , We have a double-sided whiteboard , You can flip to show one side or the other . The front will be the display （ The screen the player sees ）, And the back is hidden , Only computers can “ notice ” it . Each frame , All our paintings are on the back . then , When we're done , We flip the board over and show the new frame . This means that we only do a slow process , Talk to the monitor every frame once , Instead of doing everything on the screen .

All this is in pygame It happens automatically in . You just need to tell it to flip the whiteboard when you finish drawing . actually , The command is even named ：flip()

    #  draw 、 Rendering
    screen.fill(BLACK)
    #  Flip the display after drawing everything
    pygame.display.flip()

If you try to draw something after flipping , They will not appear on the screen ！flip()

Input / Event part

We haven't played yet , So we can't accurately say the keyboard or mouse buttons or other control events we want to monitor .

If you try to run the program now , You will find yourself having problems ： Unable to close window ！ Click “X” It doesn't work . That's because this is an event , We need to tell our program to listen for this event and let it exit the game .

Events can happen at any time . If the player clicks “ Jump ” Button , What should I do ？ Don't ignore this input , Players will feel frustrated . therefore ,Pygame All you do is save all the events that have occurred since the last frame . such , Even players quickly smash many keys , You can also record all these buttons . All events are stored in a list , So we run a loop to see all the events ：for

    for event in pygame.event.get():
        #  Check the screen close event
        if event.type == pygame.QUIT:
            running = False

Pygame There are many events . pygame.QUIT Yes, click “X” What happened when , So we set up running=False, The game cycle will end .

Control the screen refresh rate

We're not here yet “ to update ” Put anything in the section , But we still need to use our settings to control the speed . We can do that ：FPS

while running:
    #  Make sure to cycle at a normal rate
    clock.tick(FPS)

The order tells pygame How long does each cycle take , Then pause for how long , So that the whole cycle （ That is, the whole frame ） Last for the right time . If we set it to 30, It means that we want the frame to last 1⁄30 or 0.03 second . for example , If our loop code （ to update , Drawing etc. ） It only needs 0.01 second , that pygame Will wait for 0.02 second .tick() FPS

Conclusion

Last , Let's make sure that when the game cycle ends , We will actually destroy the game window . We do this by putting it at the end of the code . So our final pygame The template looks like this ：pygame.quit()

# Pygame template - skeleton for a new pygame project
import pygame
import random

WIDTH = 360
HEIGHT = 480
FPS = 30

# define colors
WHITE = (255, 255, 255)
BLACK = (0, 0, 0)
RED = (255, 0, 0)
GREEN = (0, 255, 0)
BLUE = (0, 0, 255)

# initialize pygame and create window
pygame.init()
pygame.mixer.init()
screen = pygame.display.set_mode((WIDTH, HEIGHT))
pygame.display.set_caption("My Game")
clock = pygame.time.Clock()

# Game loop
running = True
while running:
    # keep loop running at the right speed
    clock.tick(FPS)
    # Process input (events)
    for event in pygame.event.get():
        # check for closing window
        if event.type == pygame.QUIT:
            running = False

    # Update

    # Draw / render
    screen.fill(BLACK)
    # *after* drawing everything, flip the display
    pygame.display.flip()

pygame.quit()

Congratulations on ！ You have an effective Pygame Templates . Save this file with a good name , So you can start a new one every time Pygame Reuse it for projects .pygame template.py

In the next tutorial , We will use this template to learn how to draw and move objects on the screen .
